Moving Head with rotating gobos
EUROLITE TMH-155 Moving-Head

EUROLITE

Moving Head with rotating gobos

EUROLITE TMH-155 Moving-Head

Features

Moving Head with rotating gobos

  • Versatile Moving-Head with a wide range of illumination and decoration possibilities
  • 7 brilliant, dichroic colors plus white
  • 7 rotating metal gobos plus open
  • All gobos can be interchanged
  • Manual focus
  • Strobe effect with 1-13 flashes per second
  • Exact positioning within 360° Pan and 250° Tilt
  • 4-digit LED display for starting address
  • For bright 150 W discharge lamp
  • Suitable EUROLITE controllers: DMX Operator
Technical specifications
Power supply:230 V AC, 50 Hz
Power consumption:265,00 W
DMX channels:6/8
DMX connection:3-pin XLR
Flash-rate:13 Hz
Color-wheel:7 dichroic filters and open
Rotating gobo-wheel:7 gobos and open
Maximum PAN-movement:360°
Maximum TILT-movement:250°
Length of base:330 mm
Width of yoke:335 mm
Height (head horizontal):360 mm
Weight:12 kg
Legal specifications
Special product:Not designed for household room illumination
Intended use:Show effect lighting
Packaging units
PUEANWeightDimensions
1402639713053914,40 kg37cm x 38cm x 43cm
