| Input voltage: | 100 V |
| Components: | 16.5 cm speaker (6.5") |
| Rated power: | 5 W RMS (green) |
| 10 W RMS (yellow) | |
| 20 W RMS (red) | |
| COM (blue) | |
| Sensitivity: | 92 dB, ±3 dB |
| Maximum SPL: | 104 dB |
| Dimensions (D x D): | 170 x 252 mm |
| Weight: | 2.8 kg |
| Diameter: | 17 cm |
| IP classification: | IP44 |
| Size of woofer: | 17 cm (6.5") |
| Frequency range: | 110 - 15000 Hz |
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397279634 | 2,80 kg | 20,5cm x 20,5cm x 34cm |
| 6 | 4026397279641 | 18,20 kg | 65cm x 44cm x 37cm |
| Name | Version | Language |
|---|---|---|
| 00036587.pdf | 1.00 | de/en |
| Name | Version | Language |
|---|---|---|
| 00097179.pdf | 25.00 | de |
| 00097970.pdf | 25.00 | en |
| 00115073.pdf | 27.00 | de |
| 00115510.pdf | 27.00 | en |
| Name | Version | Language |
|---|---|---|
| 00023897.pdf | 1.00 | de/en |
| Name | Version | Language |
|---|---|---|
| 80710410.zip |
