LED Ball with narrow beams, 15 W 4in1 LEDs in RGBW
EUROLITE LED MFX-7 Ball

Name: EUROLITE LED MFX-7 Ball
Brand: EUROLITE
SKU: 50944320
Price: 349.00 EUR
Availability: InStock

Stock for approx. 12 wk(s)

349,00 €

Find a dealer

Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Features

LED Ball with narrow beams, 15 W 4in1 LEDs in RGBW

Beam effect with 15 W quadcolor LEDs in RGBW colors
Compact lightweight
PAN-angle adjustable between 0° and 540°
With Infinity function for unlimited PAN movement
Fan-cooled
Functions: Colored beams, auto mode, sound control, Master/Slave, built-in programs
Masterdimmer
Strobe effect with adjustable speed
DMX-controlled operation or stand-alone operation with Master/Slave function
Sound-controlled via built-in microphone
Addressing via control panel with 4-digit LED display
Standing or hanging installation possible
Switch-mode power supply for operation between 100 and 240 volts
Ready for connection with power cord and safety plug
LED: 9 x high-power 15 W 4in1 QCL RGBW
Control: Stand-alone; Sound to light via Microphone; DMX
Projection: flicker-free
Effect: Multi beam effect

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	30 W
IP classification:	IP20
Power connection:	Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
LED:	9 x high-power 15 W 4in1 QCL RGBW
Max. PAN movement:	540°
Flash rate:	0 - 25 Hz
DMX channels:	6
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Cooling:	Cooling fan
Control:	Stand-alone
	Sound to light via Microphone
	DMX
Housing color:	Black
Width:	21 cm
Height:	29 cm
Depth:	21 cm
Weight:	2.54 kg
Legal specifications
Ecodesign regulation:	Yes
Special product:	Not designed for household room illumination
Purpose:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397588446	3,20 kg	29cm x 29cm x 34cm
4	4026397588453	13,80 kg	60cm x 60cm x 37cm
