EUROLITE Set 4x LED 7C-7 Silent Slim Spot + USB QuickDMX + Case

svg
svg
svg
svg
15°
svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
7 mm
svg
svg
svg
svg
EUROLITE



EUROLITE Set 4x LED 7C-7 Silent Slim Spot + USB QuickDMX + Case

Stock for approx. 4 wk(s)
1.299,00
add to cart
Find a dealer
Due to the dimensions of this article, different shipping conditions apply.
List price excl. 19% VAT
Prices in retail stores may vary.
Item no. 20000857
Set consisting of:
mpn51915320
4 x EUROLITE LED 7C-7 Silent Slim Spot
mpn70064704
4 x EUROLITE QuickDMX USB Wireless Transmitter/Receiver
mpn31000900
1 x ROADINGER Flightcase 4x SLS Size M
Features

EUROLITE LED 7C-7 Silent Slim Spot

Silent 7in1 LED PAR spotlight in a space-saving design

  • Flat version requires minimal space when mounting
  • 7 powerful LEDs 9 W high-power 7in1 SCL RGB/CW/WW/A/UV (homogenous color mix)
  • Strobe effect
  • Integrated show programs
  • Direct color selection for 27 preset colors
  • The device is cooled by passive convection cooling
  • Control via stand-alone; DMX; IR remote control; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
  • Flicker-free
  • With a beam angle of 15°
  • Very high color rendering index (CRI)
  • With double bracket
  • 4 digit 7-segment LED display
  • Color blend stepless; Dimmer electronic
  • Silent operation
  • Preprogrammed in LED PC-Control 512; EASY SHOW 1; Light Captain; EASY SHOW 2; EASY SHOW 3
  • Mains input and output for power linking up to 8 units
  • For application areas such as: Clubs/dancing school; Wedding/gala/events; Stage; theater; mobile djs / entertainer
  • Application possibility: Standing; suspended; on stand

Package contents

  • 1 x light effect, 1 x power cord, 1 x remote control, 1 x battery, 1 x user manual

EUROLITE QuickDMX USB Wireless Transmitter/Receiver

Wireless miniature DMX transceiver 2.4 GHz, phantom powered

  • User-friendly USB plug with swivel antenna
  • Wireless DMX eliminates extensive cabling between DMX controller and the DMX-controlled units in lighting installations
  • Due to GFSK modulation with 78 channels, interference-free operation also alongside other QuickDMX transceiver and wireless devices in the 2.4 GHz band (e.g. Wi-Fi and Bluetooth)
  • Simultaneous operation of up to 6 transmitters, thus control of 3072 DMX channels (6 DMX universes) possible
  • LED indication for functions
  • Transceiver, to be used as transmitter or receiver
  • Requires 5 V phantom power for operation
  • Can receive and process up to 512 DMX channels
  • Can transmit up to 512 DMX channels
  • Control via DMX; QuickDMX; plug and play
  • Operating range up to 400m with line-of-sight

Package contents

  • 1 x device, 1 x user manual, 1 x declaration of conformity

ROADINGER Flightcase 4x SLS Size M

Trunk case, PRO version

  • Individually adjustable and removable dividers for universal use
  • With 4 Device compartments
  • High-quality workmanship with birch multiplex 7 mm, dark brown, laminated
  • Interior with foam padding
  • Aluminum profile frames 30mm with rounded edges
  • Hinged, chromium plated case handle
  • 2 chrome tip-over locks
  • 1 high-quality butterfly lock
  • Branded hardware
  • Made in Europe
  • For further information about this product, please refer to the Data Sheet under "Downloads"
Technical specifications
Weight:18,11 kg
EUROLITE LED 7C-7 Silent Slim Spot
Power supply:100-240 V AC, 50/60 Hz
Power consumption:45 W
IP classification:IP20
Power connection:Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:1 x P-Con (gray), mounting version
Fuse:5 x 20 mm, T 1 A Fuse replaceable
Lamp type:LED lamp
LED:7 x 9 W high-power 7in1 SCL RGB/CW/WW/A/UV (homogenous color mix)
Flash rate:0 - 20 Hz
DMX channels:3; 4-1; 4-2; 4-3; 4-4; 5; 6; 7; 9; 12
DMX input:1 x 3-pin XLR (M) mounting version
DMX output:1 x 3-pin XLR (F) mounting version
Cooling:Passive convection cooling
Control:Stand-alone; DMX; IR remote control; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Preprogrammed in:LED PC-Control 512; EASY SHOW 1; Light Captain; EASY SHOW 2; EASY SHOW 3
Beam angle:15°
Beam angle (1/2 peak):15°
Beam angle (1/10 peak):33°
Color rendering index (CRI):92 Ra
Housing color:Black
Attachment system:Double bracket
Display type:4 digit 7-segment LED display
USB port:Typ A
Material:Aluminum casting; metal
Dimensions:Width: 22 cm
Depth: 11 cm
Height: 25,5 cm
Weight:2,60 kg
Noise classification:Class 0 (no noise at all)
Photobiological safety:Risk Group 0
Power cord
Cable construction:3 x 1,0 mm² H05VV-F
Cable length:Approx. 1,2 m
Mounting bracket
Diameter mounting holes:1 x Ø11mm
Material:Metal, 2,5 mm
Remote control
Battery:1 x Button cell 3.0 V CR2025 lithium manganese built-in
Legal specifications
Special product:Not designed for household room illumination
Intended use:Show effect lighting
EUROLITE QuickDMX USB Wireless Transmitter/Receiver
Power supply:5 V DC
IP classification:IP20
Power connection:Mains input via USB A (M) connectable version
DMX channels:Input 512
Output 512
DMX output:1 x USB, type A
Control:DMX; QuickDMX; plug and play
Range:Range up to 400m with line-of-sight
Carrier frequency:2,4 GHz
Parallel mode:Max. 6 transmitter
Modulation:GFSK
Color:Black
Dimensions:Width: 8,6 cm
Depth: 4 cm
Height: 1,1 cm
Weight:10 g
ROADINGER Flightcase 4x SLS Size M
Maximum load:25 kg
Aluminum profile frames:30 mm
Case handle:1 pc/pcs
Stop hinge:2 pc/pcs
Lock:Butterfly lock: 1 pc/pcs
Use of brands:Branded hardware
Material:Birch multiplex, 7 mm
Color:Dark brown, laminated
Compartment dimensions:12 cm x 25 cm x 35,5 cm
Inside dimensions:49,5 cm x 25 cm x 35,5 cm
Dimensions:Width: 52,5 cm
Depth: 28,5 cm
Height: 44,5 cm
Weight:7,65 kg
Packaging units
PUEANWeightDimensions
1402639769100921,00 kg120cm x 80cm x 60cm
