High-power active PA system with DSP, 1200 watts (18" sub, 10" tops)
OMNITRONIC MAXX-1200DSP 2.1 Active System

OMNITRONIC

High-power active PA system with DSP, 1200 watts (18" sub, 10" tops)

OMNITRONIC MAXX-1200DSP 2.1 Active System

Stock for approx. 12 wk(s)
999,00
add to cart
Find a dealer
Due to the dimensions of this article, different shipping conditions apply.
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 11038831

MAXX-1200DSP 2.1 Active System

Powerful, compact active system

The MAXX-1200DSP is your compact active PA system with a high power of 1200 watts RMS. You are a mobile DJ a solo entertainer or are you playing in a small band? Then this mobile PA with its astonishing sound and good level stability is your perfect match.
Fully equipped
Power is supplied via a subwoofer with 45 cm bass speaker and two satellite speakers with 25 cm bass-midrange speaker and 3.5 cm driver. The amplifier is protected against overload and overcurrent. You can find a passive 2-way crossover with a PTC tweeter protection within the satellites.
Plug & play
You have 5 EQ presets, RCA and combined XLR and 6.3 mm inputs with XLR parallel output (to connect further systems) at your disposal. Whether you want to work with mixers, notebooks, smartphones or CD players - the MAXX gets along with all this sources.
Features
  • Mobile 2.1 system with DSP and 1200 watts RMS power
  • Provides perfect sound and good level stability in various kinds of mobile PA applications up to medium-sized party events - ideal for solo entertainers, bands and mobile discos
  • 18" subwoofer in bassreflex cabinet provides powerful, dry bass
  • Two satellites with 10" bass-midrange speakers and 1.4" driver system
  • Satellites with passive 2-way crossover, PTC tweeter protection
  • Balanced signal input XLR/6.3 mm jack L/R, with level switch
  • Additional stereo RCA input
  • Parallel XLR line output L/R
  • 5 EQ presets with indicators, DSP-controlled
  • Signal limiter, DSP-controlled
  • Separate volume control for subwoofer and satellites
  • Adjustable crossover frequency 80-200 Hz
  • Stereo/mono selection
  • Subwoofer with plywood enclosure
  • Satellites with MDF enclosure
  • Enclosure (15 mm) with scratch-resistant lacquer surface, steel grille and flange
  • Subwoofer with M20 metal flange for mounting a satellite speaker
  • Delivery includes two speaker cables
  • Transport aid: Wheels optional
  • DSP: Digital signal processor
Technical specifications
Power supply:230 V AC, 50 Hz
Amplifier power:LF 800 W RMS + HF 2 x 200 W RMS
Components:
Subwoofer:18" woofer
Satellite speakers:10" woofer, 1.4" driver
Frequency range:
Subwoofer:40-150 Hz
Satellite speakers:60-19000 Hz
Sensitivity:
Subwoofer:97 dB
Satellite speakers:96 dB
Maximum SPL:
Subwoofer:126 dB
Satellite speakers:124.5 dB
Dispersion angle:50-100° x 55°
Connection:
Line input:combination XLR/6.3 mm jack L/R
Parallel output:XLR L/R
Satellite:Speaker L/R
Dimensions (L x W x H):
Subwoofer:530 x 670 x 620 mm
Satellite speakers:525 x 335 x 306 mm
Subwoofer:38 kg
Satellite speakers:15 kg
Weight:68 kg
Power consumption:280 W 1/8 power
Size of woofer:(18") ca. 46 cm
Width:67 cm Bass; 33,5 cm Top
Depth:53 cm Bass; 52,5 cm Top
Height:62 cm Bass; 30,6 cm Top
Packaging units
PU EAN Weight Dimensions
1 4026397621778 95,50 kg 120cm x 80cm x 80cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
11038831-Manual-112219-1.00-en_de.pdf (1 MB) 1.00 en_de
