Dual oscillator (VCO)
OMNITRONIC LH-100 Audio Oscillator

Dual oscillator (VCO)-MainBild
download image
Detail images (2 overall)
1
2
OMNITRONIC

Dual oscillator (VCO)

OMNITRONIC LH-100 Audio Oscillator

The article is no longer in our assortment.
No. 10355100
Print product
Product badge
Here you find the manual and downloads for
OMNITRONIC LH-100 Audio Oscillator
The LH-100 is a voltage controlled oscillator (VCO) and allows quick and easy testing of audio circuits and speaker systems. The LH-100 generates a precise sine wave and/or square wave at a frequency adjustable from 20 Hz to 20 kHz. The oscillator is equipped with two separate level controls for sine and square wave as well as a -10 dB pad to attenuate the output level. Via the VCO input you can connect external audio signal sources to determine the oscillator's frequency.
Features

Dual oscillator (VCO)

  • The LH-100 is voltage controlled (VCO) and produces sine and square wave audio signals to test audio equipment such as speaker systems
  • 2 separate outputs with variable amplitudes
  • Variable frequency from 20 Hz to 20 kHz (deactivated at VCO input signal)
  • Additional audio input for an external signal source
  • -10 dB pad for output attenuation
  • Feed-through output for supplying a further LH-100 with power
  • All audio connections via 6.3 mm jacks (1/4")
  • Operation via supplied power unit
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
12-16V
Power connection:Mains input via coaxial power connector (M) mounting version power supply cord with AC adapter (provided)
Frequency range:20 - 20000 Hz variable
Input attenuation:-10 dB
Gain:-10 dB
Connections:Input: 1 x 6.3 mm plug (unbal.)
Output: 2 x 6.3 mm plug (unbal.)
Dimensions:Width: 11,5 cm
Depth: 9,2 cm
Height: 4 cm
Weight:0,53 kg
Packaging units
PUEANWeightDimensions
140263973019150,72 kg23cm x 13cm x 8cm
20402639730478715,50 kg68cm x 47cm x 19cm
Support
Spare parts
No spare parts available.
