2-way multi-function speaker-system
OMNITRONIC PAS-212 MK2 2-way top

2-way multi-function speaker-system-MainBild

2-way multi-function speaker-system

OMNITRONIC PAS-212 MK2 2-way top

L'articolo non è più disponibile.

No. 11039424

Qui troverai le istruzioni per l'uso e i download per
OMNITRONIC PAS-212 MK2 2-way top

PAS-series
Our upper class speakers in wooden cabinets. And although the PAS-series is of top-quality workmanship, features a steel chassis, an unbalanced, rotatable horn with heavy-duty coil driver, and a bassreflex system it comes at a very favorable price. Moreover, it has a torsion-resistant aluminum chassis and is made of light-weight, yet solid multiplex wood.

The series abbrevations MK1 and MK2 determine the different crossovers, which have been optimized throughout the years. Every version can be modified into another version by installing a replacement crossover.

PAS-speakers can be used in many ways (lying, standing, flying, on distance tubes, in clusters). A completion to the series are the subwoofers which are powerful and persuasive.

Particularly worth mentioning are the four different wall-mounting systems (tiltable and swivelable, rotatable, tiltable on distance tubes, adjustable against walls) which allow for an unbelievably variety of applications.

Features

2-way multi-function speaker-system

Rugged full-range top speaker in a stable wooden housing
Trapezoidal multi-functional housing with monitor shape
Qualified for suspended installation
Rotatable constant directivity horn (asymmetrical) with coil-driver
With passive 2-way crossover
Powerful, dry bass via voluminous housing with bass-reflex system
For applications requiring enhanced bass punch, we recommend a combination with the PAS-subwoofers
Balanced frequency range with high sound-pressure
Very high durability
Housing made of several layer, 18-mm birch plywood
Scratch-resistant lacquer surface
Impact-resistant steel grille with acoustic foam
Can be used lying, standing, on a subwoofer, on a speaker-stand or stand or suspended
With flange for speaker-stand installation etc.
Compact speaker-system for car transport
Very large amplification systems can be realized via several PAS speaker-systems and the respective power amplifiers
Ideal as PA system or amplification system for medium-sized and large discotheques
Per maggiori informazioni su questo prodotto, consultare "Download" nella scheda tecnica

Dati tecnici

Intervallo di frequenza:	58 - 20000 Hz
Misure:	Larghezza: 37,5 cm Profondità: 40 cm Altezza: 62 cm
Peso:	21,30 kg
Rated power:	300 W RMS
Program power:	600 W
Components:	30 cm woofer (12"), 2.5 cm horn (1")
Connection:	2 Speaker sockets
Sensitivity:	98 dB
Maximum SPL:	125 dB
Impedance:	8 ohms
Dispersion angle:	50-100° x 55°
Dimensions (H x W x D):	620 x 375 x 400 mm
