Moving Head Wash with 3 W Luxeon Rebel RGBW LEDs
FUTURELIGHT EYE-108 Moving-Head Wash

FUTURELIGHT

Moving Head Wash with 3 W Luxeon Rebel RGBW LEDs

FUTURELIGHT EYE-108 Moving-Head Wash

Item no. 51841339

Features
  • Equipped with 108 x 3 W high power LEDs "Luxeon Rebel" made by Lumileds, USA
  • LEDs: 52 x red, 22 x green, 22 x blue, 12 x white
  • Correction of the color temperature via 12 cold white LEDs possible
  • Luxeon Rebel LEDs have a very high brightness and extreme long life
  • Long LED life
  • DMX-controlled operation or stand-alone operation with Master/Slave function
  • 56 preprogrammed scenes in Program Run for stand-alone operation
  • Number of scenes in Program Run can be changed individually
  • The scenes in Program Run can be modified via the Control Board or via an external controller and loaded into the memory
  • 7 built-in programs can be called up via DMX controller
  • Software upload by optional FUTURELIGHT ULB-1 upload box via DMX link (from software version 2.0, 06/2010)
  • Sound-controlled via built-in microphone
  • Exact positioning via 16-bit Pan/Tilt movement resolution
  • PAN angle switchable between 630° and 540°
  • Switch-mode power supply
  • Automatic power supply adaption between 100 and 240 Volts without power selector
  • Stepless RGBW color changing
  • Programmable color change speed and strobe effect
  • Random strobe effect
  • Lightbeam with 40° radiation angle
  • Blue LCD display
  • Upgrade via further optional module: wireless receiver for W-DMX operation
  • ESDC function (Easy Service Data Check) with battery-buffered Control Board for operation time readouts etc.
  • Strobe effect with 1-25 flashes per second
  • Masterdimmer
  • Rainbow effect
  • Control Board with LCD display and foil-keyboard for adjusting the DMX-starting address, Pan/Tilt Reverse, Program, Reset
  • RDMX (Remote DMX Addressing): DMX address setting via controller possible
  • Advantages of LED technology: long life, low power consumption, minimal heat emission, defacto maintenance free with brilliant light radiation
  • DMX control via every standard DMX controller
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
DMX channels:13
DMX connection:3-pin XLR
Flash-rate:25 Hz
Maximum PAN-movement 630°:in 2.5 s
Maximum TILT-movement 265°:in 1.5 s
LED number:108
Beam angle:40°
Dimensions (L x W x H):325 x 230 x 445 mm
Weight:10 kg
Power consumption:340.00 W
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
Packaging units
PU EAN Weight Dimensions
1 4026397383232 11,35 kg 47cm x 35cm x 43cm
