EUROLITE Set 2x LED TMH-H90 Hybrid Moving-Head Spot/Wash COB wh + Case

svg
svg
svg
13° spot
svg
20° Wash effect
svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
7 mm
svg
svg
svg
EUROLITE



EUROLITE Set 2x LED TMH-H90 Hybrid Moving-Head Spot/Wash COB wh + Case

delivery date unknown
1.499,00
add to cart
Find a dealer
Due to the dimensions of this article, different shipping conditions apply.
List price excl. 19% VAT
Prices in retail stores may vary.
Item no. 20000922
Set consisting of:
mpn51786078
2 x EUROLITE LED TMH-H90 Hybrid Moving-Head Spot/Wash COB wh
mpn31001077
1 x ROADINGER Flightcase 2x TMH-S90/H90/B90
Features

EUROLITE LED TMH-H90 Hybrid Moving-Head Spot/Wash COB wh

LED Moving Head hybrid spot/wash with color wheel, static and rotating gobo wheel, prism and focus

  • Bright spotlight and full-fledged washlight in one device
  • Positioning within 540° PAN and 200° TILT
  • Exact positioning via 16 bit PAN/TILT movement resolution
  • Rotating 3-facet prism with variable speed
  • Strobe effect with 2-30 flashes per second
  • Built-in programs
  • Electronic dimmer (0-100%)
  • Automatic position correction
  • 1 powerful LED 90 W COB (chip-on-board) cold white (CW)
  • 6 powerful LEDs 10 W high-power 6in1 HCL RGBWA/UV (homogenous color mix)
  • Color wheel 1 x 7 dichroic filters plus open
    Rainbow effect with adjustable speed in both directions
  • Gobo wheel with static gobos, 7 gobos and open
    shake effect
  • Gobo wheel with rotating gobos, 6 gobos and open
    shake effect
  • Gobos changeable
  • Slot-in gobo system for exchanging gobos without tools
  • Can be operated in 25 CH mode
  • The device is cooled by cooling fan
  • Controlling by stand-alone; DMX; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
  • Preprogrammed in Light Captain
  • Flicker-free
  • Effect: Gobo effect
  • With a beam angle of 13°
  • Multicolor LCD display for easy controlling

Package contents

  • 1 x Moving light, 1 x User manual, 1 x Power cord, 1 x Omega holder, 1 x Safety eyelet

ROADINGER Flightcase 2x TMH-S90/H90/B90

Flightcase for 2 x EUROLITE LED TMH-S90 Moving-Head Spot

  • For optimal security
  • With 2 Device compartments
  • High-quality workmanship with plywood glued 7 mm, black, laminated
  • Interior with foam padding
    cover with foam padding
  • Aluminum profile frames 30mm with rounded edges
  • 2 hinged, chromium plated case handles
  • 2 chrome tip-over locks
  • 2 high-quality butterfly locks
  • With castors
Technical specifications
Weight:26,15 kg
EUROLITE LED TMH-H90 Hybrid Moving-Head Spot/Wash COB wh
Power supply:100-240 V AC, 50/60 Hz
Power consumption:135 W
IP classification:IP20
Protection class:Class I
Power connection:Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Fuse:5 x 20 mm, T 2 A Fuse replaceable
Lamp type:LED lamp
LED:1 x 90 W COB (chip-on-board) cold white (CW)
6 x 10 W high-power 6in1 HCL RGBWA/UV (homogenous color mix)
Max. TILT movement:Exact positioning (16 bit resolution) 200° Auto position correction (feedback)
Max. PAN movement:Exact positioning (16 bit resolution) 540° Auto position correction (feedback)
Flash rate:2 - 30 Hz
Equipment:Prism 3-fold; gobo wheel with rotating gobos Single in slot; gobo wheel with static gobos; Focus motor-driven; color wheel
Color generation:Color wheel 1 x 7 dichroic filters plus open
Gobos:Gobo wheel with static gobos, 7 gobos and open
Shake effect
Gobo wheel with rotating gobos, 6 gobos and open
Outside diameter 21,8mm
Image diameter 16mm
Shake effect
Gobos changeable
Slot-in gobo system for exchanging gobos without tools
DMX channels:25
DMX input:3-pin XLR (M) mounting version
DMX output:3-pin XLR (F) mounting version
Cooling:Cooling fan
Control:Stand-alone; DMX; Sound to light via Microphone; Master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); Light Captain
Beam angle:13°
Beam angle (1/2 peak):Spot 13°
Wash effect 20°
Beam angle (1/10 peak):Wash effect 38°
Illuminance in Lux (lx):Spot cold white (CW) 1m: 49373 lx, 3m: 6186 lx, 6m: 1606 lx
Wash effect red (R) 1m: 974 lx, 3m: 101 lx, 6m: 26 lx
Wash effect green (G) 1m: 2008 lx, 3m: 244 lx, 6m: 66 lx
Wash effect blue (B) 1m: 518 lx, 3m: 49 lx, 6m: 13 lx
Wash effect cold white (CW) 1m: 2527 lx, 3m: 257 lx, 6m: 69 lx
Wash effect amber (A) 1m: 733 lx, 3m: 83 lx, 6m: 21 lx
Wash effect ultra violet (UV) 1m: 16 lx, 3m: 2 lx, 6m: 1 lx
Wash effect all 1m: 5885 lx, 3m: 703 lx, 6m: 184 lx
Housing color:White
Display type:Multicolor LCD display
Dimensions:Width: 25,0 cm
Depth: 22,0 cm
Height: 36,0 cm
Weight:6,50 kg; 6,50 kg
Noise classification:Class 3 (clearly perceptible sounds)
Legal specifications
Special product:Not designed for household room illumination
Intended use:Show effect lighting
ROADINGER Flightcase 2x TMH-S90/H90/B90
Maximum load:50 kg
Aluminum profile frames:30 mm
Case handles:2 pc/pcs
Stop hinge:2 pc/pcs
Lock:Butterfly lock: 2 pc/pcs
Transport aid:Castors
Material:Plywood glued, 7 mm
Color:Black, laminated
Device compartment:20 cm x 26 cm x 37 cm
Accessory compartment:9,5 cm x 26 cm x 37 cm
Dimensions:Width: 57 cm
Depth: 32 cm
Height: 54 cm
Weight:13,15 kg
Packaging units
PU EAN Weight Dimensions
1 4026397706987 29,00 kg 130cm x 50cm x 30cm
