FUTURELIGHT



FUTURELIGHT Set 2x Color Mega Wave.i + Case

Item no. 20000182
Set consisting of:
mpn51839010
2 x FUTURELIGHT Color Mega Wave.i LED Moving Bar
mpn31005076
1 x ROADINGER Flightcase 2x Mega Wave
Features

FUTURELIGHT Color Mega Wave.i LED Moving Bar

4in1 moving-head with two separately tiltable LED bars and six beams with 40 W COB LEDs

  • With Infinity function for unlimited PAN movement
  • TILT movement for each LED bar separately and steplessly adjustable
  • Equipped with six 40 W LEDs with RGBW colors
  • Upgrade via optional wireless receiver module for WDMX operation (Wireless Solution - made in Sweden)
  • 17, 18, 20 or 39 DMX channels selectable
  • Each LED can be controlled individually
  • Narrow illumination angle
  • Functions: built-in programs, shutter sequences, color presets for each LED independently controllable, countless RGBW colors, dimmer, strobe effect with variable speed, sound-control, Master/Slave operation
  • Automatic position correction
  • Exact positioning via 16 bit PAN/TILT movement resolution
  • Random strobe effect
  • DMX-controlled operation or stand-alone operation with Master/Slave function
  • Control board with graphic LCD and foil-keyboard for adjusting the DMX-starting address, PAN/TILT reverse, reset
  • The scenes can be modified via the Control Board or via an external controller and loaded into the memory
  • Number of scenes can be changed individually
  • Software upload by optional accessories via DMX link
  • ESDC function (Easy Service Data Check) with battery-buffered control board for operation time readouts etc. (the Li-Ion battery 3.7V, AAA, 10440 is not included)
  • Switch-mode power supply for operation between 100 and 240 Volts
  • Power connection via Neutrik PowerCon jack and included power cable
  • Feed-through output allows to power up to 8 devices
  • DMX control via every standard DMX controller
  • 6 powerful LEDs 40 W COB (chip-on-board) 4in1 QCL RGBW (homogenous color mix)
  • Auto position correction (feedback)
  • Exact positioning (16 bit resolution)
  • Fan effect
  • The device is cooled by temperature-controlled fan
  • Control via RDM; DMX; stand-alone; W-DMX by wireless solution; Sound to light via Microphone
  • Preprogrammed in LED PC-Control 512
  • Flicker-free
  • With a beam angle of 7°

ROADINGER Flightcase 2x Mega Wave

PRO flightcase for 2x Mega Wave

  • Fitted for 2 devices and accessory
  • Additional accessory compartment
  • Interior upholstered with foam
  • High-quality workmanship with birch multiplex
  • Aluminum profile frames with rounded edges
  • Three-leg, big steel ball corners
  • Lid with 2 tip-over locks
  • 2 chrome butterfly locks
  • 4 chrome case handles
  • Castors
  • Branded hardware
  • For further information about this product, please refer to the Data Sheet under "Downloads"
Technical specifications
Weight:46,90 kg
FUTURELIGHT Color Mega Wave.i LED Moving Bar
Power supply:100-240 V AC, 50/60 Hz
Power consumption:200 W
IP classification:IP20
Power connection:Mains input via PowerCON (blue), mounting version power supply cord with safety plug (provided)
Power output:1 x PowerCON (gray), mounting version
Lamp type:LED lamp
LED:6 x 40 W COB (chip-on-board) 4in1 QCL RGBW (homogenous color mix)
Max. TILT movement:240° Exact positioning (16 bit resolution) Auto position correction (feedback)
Max. PAN movement:Exact positioning (16 bit resolution) plus infinity Auto position correction (feedback)
Flash rate:0 - 20 Hz
DMX channels:17; 18; 20; 39
DMX input:1 x 5-pin XLR (M) mounting version
1 x 3-pin XLR (M) mounting version
DMX output:1 x 5-pin XLR (F) mounting version
1 x 3-pin XLR (F) mounting version
Cooling:Temperature-controlled fan
Control:RDM; DMX; stand-alone; W-DMX by wireless solution; Sound to light via Microphone
Preprogrammed in:LED PC-Control 512
Beam angle:
Beam angle (1/2 peak):
Beam angle (1/10 peak):
Illuminance in Lux (lx):Red (R) 3m: 3209 lx, 6m: 1777 lx
Green (G) 1m: 0 lx, 3m: 6717 lx, 6m: 2801 lx
Blue (B) 3m: 820 lx, 6m: 421 lx
Cold white (CW) 3m: 6993 lx, 6m: 3347 lx
All 3m: 16094 lx, 6m: 7504 lx
Housing color:Black
Dimensions:Width: 25 cm
Depth: 53,8 cm
Height: 34,2 cm
Weight:12,85 kg
Legal specifications
Special product:Not designed for household room illumination
Intended use:Show effect lighting
ROADINGER Flightcase 2x Mega Wave
Maximum load:100 kg
Transport aid:Castors
Use of brands:Branded hardware
Material:Birch multiplex, 7 mm
Color:Dark brown, laminated
Dimensions:Width: 73 cm
Depth: 62 cm
Height: 55 cm
Weight:21,20 kg
Strength:7 mm
Outside dimensions (W x D x H):730 x 620 x 550 mm
