Multifrequency wireless receiver, diversity system
OMNITRONIC DR-415 Wireless receiver

Name: OMNITRONIC DR-415 Wireless receiver
Brand: OMNITRONIC

The article is no longer in our assortment.

Print product

Features

16 UHF frequencies (800.100 - 813.000 MHz) selectable via DIP switches
Diversity system with two antennas
Operation in the low-interference UHF band
LED display for power supply and signal input
Squelch control to eliminate noise bursts
Output level control
6.3 mm and XLR output
Operation via supplied power unit
A wireless microphone or a belt transmitter with lavalier microphone or headset microphone can be ordered separately
License-free and approved in Germany

Technical specifications

System:	Switching Diversity, one channel
Carrier frequency:	UHF 800.100-813.000 MHz (16 ch.) 800.875, 801.375, 802.375, 803.125, 803.875, 804.500, 805.125, 805.875, 806.625, 807.375, 807.875, 808.375, 809.125, 810.250, 810.875, 811.875 MHz
Frequency stability:	±0,005 %
T.H.D.:	<1 % at 1 kHz
Tone signal:	32.768 kHz
S/N-ratio:	>94 dB at 48 kHz deviation and 60 dB antenna input
Input sensitivity:	8 dB
Selectivity:	>50 dB
Dynamic range:	>96 dB
Modulation method:	FM-frequency modulation
Coverage:	>80 m (with line-of-sight)
AF response:	50-15000 Hz (±3 dB)
Audio output:	Mono 6.3 mm jack socket or balanced XLR
Power supply:	12 V DC
Dimensions:	210 x 165 x 44 mm
Weight:	0.55 kg
Power consumption:	140.00 W

Packaging units

PU	EAN	Weight	Dimensions
1	4026397114003	1,30 kg	33,1cm x 35,5cm x 7cm
5	4026397270204	8,20 kg	37cm x 36cm x 33cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

Loading spareparts. Please wait...

Downloads

User manual

Name	Version	Language
00043619.pdf	1.30	de/en/fr/es
Rack Installation DR-SR 00051524.pdf	0.00	en

Service document

Name	Version	Language
00002121.pdf	0.00	de/en/fr/es

All images

Name	Version	Language
13061100.zip
