| Power supply: | 100-240 V AC, 50/60 Hz |
| via supplied power unit | |
| Power consumption: | 10 W |
| Gain: | |
| Line: | 20 dB |
| Phono: | 60-75 dB |
| Mic: | 44 dB |
| Max. output level: | 22 dBu |
| Frequency range: | |
| Line: | 20-20000 Hz |
| Phono: | 40-18000 Hz |
| Mic: | 20-20000 Hz |
| S/R ratio: | |
| Line: | 85 dB |
| Phono: | 77 dB |
| Mic: | 80 dB |
| THD: | |
| Line: | <0.03 % |
| Phono: | <0.1 % |
| Frequency isolator: | |
| Lows: | 20 Hz to 300 Hz |
| Mids: | 300 Hz to 4 kHz |
| Highs: | 4 kHz to 20 kHz |
| Inputs: | |
| LINE: | RCA L/R |
| PHONO: | RCA L/R |
| DJ microphone: | XLR |
| Outputs: | |
| MASTER: | XLR/RCA L/R |
| BOOTH: | XLR/RCA L/R |
| REC: | RCA L/R |
| Headphones output: | 6.3 mm jack (min. 32 ohms) |
| Dimensions (W x D x H): | 235 x 190 x 95 mm |
| Weight: | 3,3 kg |
| Height: | 9,5 cm |
| Depth: | 19 cm |
| Width: | 23,5 cm |
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397541816 | 3,54 kg | 45cm x 24cm x 13,5cm |
| 6 | 4026397556100 | 23,15 kg | 52cm x 48cm x 43cm |
| Name | Version | Language |
|---|---|---|
| 10355921-Manual-92522-1.00-de_en.pdf (3 MB) | 1.00 | de_en |
| Name | Version | Language |
|---|---|---|
| 10355921-Page-97399-25.00-de.pdf (322 KB) | 25.00 | de |
| 10355921-Page-97836-25.00-en.pdf (320 KB) | 25.00 | en |
| Name | Version | Language |
|---|---|---|
| 10355921-Video-100570-es_fr_en_de.flv (39 MB) | 0.00 | es_fr_en_de |
| Name | Version | Language |
|---|---|---|
| 10355921-Images.zip |
