EUROLITE Spot PAR-64 alu + Rayl. + Lamp 500W

310°

20,3 cm

filter frame 20,2 cm

EUROLITE Spot PAR-64 alu + Rayl. + Lamp 500W

The article is no longer in our assortment.

No. 09004172

Print product

Product badge

Set consisting of:

1 x EUROLITE Raylight PAR-64,GY-9.5 Socket long

1 x EUROLITE PAR-64 Spot Long with Cable sil

2 x OMNILUX A1 230V/500W GY-9.5 75h

Features

EUROLITE Raylight PAR-64,GY-9.5 Socket long

The alternative to traditional lamps

Immediately and without changing the wiring, exchangeable by flanged on pin socket (GX 16) against a PAR-64 lamp
Cost savings, as only the burner must be replaced at a lamp change
Longlife lamp types (up to 2.000 h) also save time and money
Low weight

EUROLITE PAR-64 Spot Long with Cable sil

Long PAR-64 housing (with open cable ends)

4 clip-to-hold clamps with spring locks for comfortable opening of the color filter frame
Safety grille (splinter protection) is integrated in the tube
Strong clamps with extension springs for safe hold and for quick opening of the rear housing cover
Blackened tube for precise light output
Strong cable tension relief
With mounting bracket
Available in various colors
For PAR 64
For application areas such as: Advertisement/Shop window; decoration; clubs/dancing school

Package contents

1 x spotlight, 1 x filter frame, 1 x lamp clamping ring, 1 x user manual

OMNILUX A1 230V/500W GY-9.5 75h

Special lamp for show effect lighting

One-sided base
Easy lamp replacement
Dimmable
Very high color rendering index (CRI)

Technical specifications

Weight:	1,81 kg
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting
EUROLITE Raylight PAR-64,GY-9.5 Socket long
Power supply:	230 V AC, 50 Hz
Power consumption:	500 W
Base:	GY9.5; GX16d
Beam angle (1/2 peak):	NSP
Color:	Alu colored
Dimensions:	Diameter: Ø 20,3 cm
Weight:	0,14 kg
EUROLITE PAR-64 Spot Long with Cable sil
Power supply:	230 V AC, 50 Hz
Power consumption:	Max. 1000 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Fixed supply cord with open wires
Cable length:	Approx. 0,7 m
Base:	GX16d
Lamp type:	Selectable
Color generation:	Via color filter frame (optional)
Housing color:	Silver
Attachment system:	Mounting bracket
Slot for spot length:	25,7 cm x 25,7 cm
Dimensions:	Length: 41,5 cm Width: 26,5 cm Height: 34,5 cm
Weight:	1,63 kg
Filter frame
Dimensions:	Length: 25,5 cm Width: 25,5 cm Diameter: Ø 20,2 cm
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting
OMNILUX A1 230V/500W GY-9.5 75h
Voltage (lamps):	230 V, AC
Nominal wattage:	500 W
Base:	GY9.5
Lamp type:	Halogen lamp
Lamp specification:	Dimmable
Beam angle:	310°
Color of light:	White
Color temperature:	2700K
Color rendering index (CRI):	100 Ra
Lead time:	0,2 s
Construction:	Bi pin
Operating temperature max.:	40° C
Operating temperature min.:	20° C
Burning position:	S180 (universal)
Lamp life:	75 h
Luminous flux:	7200 lm
Wavelength:	778 nm
Lamp current:	2,17 A
Dimensions (LxD):	78x18 mm
Weight:	0,02 kg
Energy efficiency class (A - G):	G
EPREL-Nr:	1519666
