EUROLITE Spot PAR-64 alu + Rayl. + Lamp 500W

EUROLITE



EUROLITE Spot PAR-64 alu + Rayl. + Lamp 500W

Item no. 09004172

svg
310°
svg
20,3 cm
svg
Features

51000750 EUROLITE Raylight PAR-64,GY-9.5 Socket long

The alternative to traditional lamps

  • Immediately and without changing the wiring, exchangeable by flanged on pin socket (GX 16) against a PAR-64 lamp
  • For all GY-9.5 lamps, thus, many different light performances are selectable
  • Neat, precisely focused light output
  • Cost savings, as only the burner must be replaced at a lamp change
  • Longlife lamp types (up to 2.000 h) also save time and money
  • For all PAR-64 spots except PAR-64 short version
  • Low weight for reduced traverse charge

42100950 EUROLITE PAR-64 Spot Long with Cable sil

Long PAR-64 housing (open cable ends)

  • Spotlight housing for decoration or display windows, discotheques
  • Comes completely wired with GX16 pin connector and color filter frame
  • Comes fully-wired with black silicone cable, stable earthing in the housing and directly clamped ceramic socket
  • Protection grille on the rear housing cover - complies with CE-regulations
  • For lamps with max. 1000 W
  • 4 clip-to-hold clamps with spring locks for comfortable opening of the color filter frame
  • Safety grille (splinter protection) is integrated in the tube
  • Strong clamps with extension springs for safe hold and for quick opening of the rear housing cover
  • Swivel mounting bracket
  • Blackened tube for precise light output
  • Strong cable tension relief
  • Supplied without lamp
  • Silver or black housing available
  • Power plug has to be ordered separately
  • Case color: Silver
  • Color generation: Via color filter frame (optional)
  • Power connection: Fixed Main input cable with open wires
  • Control: without

88384005 OMNILUX A1 230V/500W GY-9.5 75h

Studio-lamp for base GY-9.5

  • Base one-sided
  • Easy replacement of lamps
  • Rated voltage 230 V
  • Color rendering index (CRI) more than: 100 Ra
Technical specifications
51000750 EUROLITE Raylight PAR-64,GY-9.5 Socket long
Light beam:Narrow Spot
Base:Universal GY 9,5
Rated voltage:max. 250 V
Rated power:max. 500 W
Color:Alu colored
Weight:0,14 kg
Power consumption:500 W
Base:GY9.5; GX16d
Power supply:230 V AC, 50 Hz
Diameter:20,3 cm
42100950 EUROLITE PAR-64 Spot Long with Cable sil
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
Weight:1,5 kg
IP classification:IP20
Power consumption:1000 W
Height:34,5 cm
Width:26,5 cm
Power connection:Fixed Main input cable with open wires
Depth:41,5 cm
Power supply:230 V AC, 50 Hz
88384005 OMNILUX A1 230V/500W GY-9.5 75h
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
Base:GY9.5
Voltage (lamps):230 V
Operating voltage (lamps):220 - 240
Nominal wattage:500 W
Beam angle (bulb):310°
Color of light:White
Color temperature:3200K
Dimmable:Dimmable
Weight:0,0163 kg
