OMNITRONIC Set TM-250 + VHF-250 179MHz

svg
Microphone 5 cm
svg
OMNITRONIC



OMNITRONIC Set TM-250 + VHF-250 179MHz

Item no. 09000391

Features

13075006 OMNITRONIC TM-250 Transmitter VHF179.000

VHF pocket transmitter set for TM-250

  • Set includes transmitter and lavalier microphone
  • Matches receiver VHF-250 with the same carrier frequency
  • Operation with fixed VHF frequency 179.000 MHz
  • On/Off/Mute operation selector
  • LED indicator for battery capacity
  • Transmitting power 8.5 mW
  • 3.5 mm jack (1/8") screw connection to headset or lavalier mic
  • Power supply via 9 V battery (supplied)
  • License-free and approved in Germany and other EU countries
  • Polar pattern: Cardioid
  • Battery: 1 x 9.0 V E block (provided)

13073012 OMNITRONIC VHF-250 Wireless Mic Set 179

Complete VHF diversity wireless microphone system

  • Set includes receiver unit and one wireless microphone
  • Matches transmitter TM-250 with the same carrier frequency
  • Switching diversity system with two folding antennas
  • LED indicator for power, signal input and AF peak
  • Output level control
  • Squelch control to eliminate noise bursts
  • 6.3 mm and XLR output
  • Microphone with gain control
  • 1 m jack-jack cable included
  • License-free and approved in Germany and other EU countries

Microphone

  • Polar pattern: Cardioid
  • Battery: 1 x 9.0 V E block (provided)
Technical specifications
13075006 OMNITRONIC TM-250 Transmitter VHF179.000
Type:Pocket transmitter
Power connection:Battery/battery pack
Polar pattern:Cardioid
Battery:1 x 9.0 V E block (provided)
Frequency band:VHF
Capsule type:Condenser
Carrier frequency:179 MHz
Material:Plastic
Width:6,5 cm
Height:10,7 cm
Depth:3,2 cm
Weight:0,17 kg
Modulation:FM, F3F
Frequency stability:<±30 ppm
T.H.D.:<0.5 % at 1 kHz
Band width:40-15 kHz (±3 dB)
Maximum deviation:±25 kHz
RF power output:8.5 mW
13073012 OMNITRONIC VHF-250 Wireless Mic Set 179
Type:Wireless set
Power connection:Battery/battery pack
Frequency band:VHF
Frequency range:50 - 20,000 Hz
S/N ratio:>90 dB
Range:50 m
Carrier frequency:179 MHz
Material:Plastic
Weight:1,00 kg
Receiver
Power supply:230 V AC, 50 Hz
15 V DC 300 mA
Power consumption:2,5 W
Power connection:Mains input Coaxial power connector (M) Power supply cord with AC adapter (provided)
Width:19,5 cm
Height:4 cm
Depth:14 cm
Microphone
Power supply:9 V DC
Polar pattern:Cardioid
Battery:1 x 9.0 V E block (provided)
Capsule type:Dynamic
Length:26 cm
Diameter:5 cm
Weight:0,255 kg
Wireless receiver:Switching diversity, one channel
Frequency stability:±0.005 %
Selectivity:>80 dB
Dynamic range:>80 dB
Modulation method:FM frequency modulation
Audio output:mono 6.3 mm jack socket, XLR jack
RF power output:8.5 mW
Current consumption:approx. 65 mA
