Rugged truss lifter for medium-heavy loads

EUROLITE STC-550/180 Truss Lifter TÜV/GS

L'articolo non è più disponibile.

Guarda le alternative:

BLOCK AND BLOCK SIGMA-70 Sollevatore traversa 160kg 5,3 m

un'alternativa interessante, da non perdere!

La giacenza è di circa 12 sett.

1.349,00 €

BLOCK AND BLOCK OMEGA-30 Sollevatore traversa 220kg 5m

un'alternativa interessante, da non perdere!

La giacenza è di circa 12 sett.

2.699,00 €

No. 59007060

Stampa l'articolo

Etichetta articolo

The EUROLITE STC-series are truss lifters manufactured under strict TUV monitoring. These lifts boast of high quality, exraordinary ruggedness, highest versatility and high stability. The production is monitored by the German TÜV SÜD which means that they comply with the highest safety standards.

The GS mark signals to the buyer, customer, or consumer that the chosen product as well as the user manual and production (process) have been tested by an authorized institution such as TÜV SÜD, with priority being given to aspects of safety. In the meantime, the German GS-mark has been recognized as one of the crucial marks within product safety.

Features

Rugged truss lifter for medium-heavy loads

Four-part telescopic lifter with galvanized steel sections
1-gear winch for easy lifting of the loads
Automatic braking system
Safety bolt for mechanical locking
Four massive outriggers for highest stability
Outriggers are firmly connected with the base, the finishing is velcro-protected
Uneven grounds can be compensated via individually adjustable levelling braces
Four auto-levelling, galvanized foot plates
Powder-coated base and galvanized sections for highest corrosion protection
Complies with DIN EN ISO 12100-2 and DIN 15560-27
Regolabile in altezza
4 ruote girevoli with 2 locking brakes
Certificato TÜV/GS

Dati tecnici

Portata massima:	180 kg
Carico minimo:	25 kg
Norma:	DIN EN ISO 12100-2, DIN 15560-27
Altezza:	Maximum: 550 cm above 4 sections Minimum: 177 cm
Sistema di registrazione:	55mm x 55mm
Fune d'acciaio:	Ø 5 mm
Tipo (treppiede generico):	Sollevatore a traversa
Ausilio di trasporto:	4 x ruote girevoli with 2 locking brakes
Materiale:	Acciaio, 2 mm
Dimensioni di trasporto:	177 cm x 60 cm x 46 cm
Superficie espositiva:	Ø 217 cm
Peso:	107,00 kg

Unità di imballaggio

QPC	EAN	Peso	Dimensioni
1	4026397277937	115,60 kg	185cm x 51cm x 53cm

Accessori

L'accessorio viene caricato. Attendi...

Assistenza

Pezzi di ricambio

EUROLITE Winch handle complete for STC-550

EUROLITE castor horizontal for STC-480/550

EUROLITE Rolle (vertical) for STC-310/480/550

Altri 4 pezzi di ricambio
