Weatherproof speaker, LF: 6.5" HF: 1" - 100 V 20/40/80 W RMS
OMNITRONIC HS-80 PA Horn Speaker

OMNITRONIC

Weatherproof speaker, LF: 6.5" HF: 1" - 100 V 20/40/80 W RMS

OMNITRONIC HS-80 PA Horn Speaker

Stock for approx. 12 wk(s)
199,00
add to cart
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 80710828

Features
  • 2-way horn speaker for 100 V operation
  • 4 power taps (10 W, 20 W, 40 W, 80 W)
  • 16.5 cm woofer (6.5") and 2.5 cm tweeter (1")
  • PTC tweeter protection
  • High sound pressure and wide frequency range
  • Weather-proof plastic housing (IP44)
  • Octagonal enclosure
  • Swivable mounting bracket
  • Connection via terminal strip
  • For outdoor amplifying systems in football stadiums, outdoor pools, open air events
Technical specifications
Input voltage:100 V
Components:16.5 cm woofer (6.5") and 2.5 cm tweeter (1")
Rated power:10 W RMS (green)
20 W RMS (white)
40 W RMS (yellow)
80 W RMS (red)
COM (black)
Sensitivity:99 dB
Protection grade:IP44
Dimensions (H x W x D):348 x 348 x 288 mm
IP classification:IP44
Weight:5,3 kg
Frequency range:90 - 20000 Hz
Packaging units
PU EAN Weight Dimensions
1 4026397523072 7,15 kg 36,5cm x 36,5cm x 36,5cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
00084072.pdf 1.10 de/en
Catalog pages
Name Version Language
00097185.pdf 25.00 de
00097976.pdf 25.00 en
00115069.pdf 27.00 de
00115506.pdf 27.00 en
All images
Name Version Language
80710828.zip
