6-zone PA mono mixing amplifier, 250 watts, zones switchable
OMNITRONIC MPZ-250.6 PA Mixing Amplifier

OMNITRONIC

6-zone PA mono mixing amplifier, 250 watts, zones switchable

OMNITRONIC MPZ-250.6 PA Mixing Amplifier

Stock for approx. 12 wk(s)
419,00
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 80709731

Enormous reliability with a maximum of flexibility

The Omnitronic MPZ-250.6 ELA mixer amplifier is your reliable partner for ELA sound reinforcement systems. Thanks to its 19" format, it is ideally suited for both mobile and permanent installations.
Outputs for ELA loudspeakers with 70 V and 100 V audio transformers or 4-16- Ohm loudspeakers leave nothing to be desired. In addition, you can also connect a device with line level (e.g. mixing console) to the line output. With 6 mixable inputs you are always flexible. Connect up to 3 microphones and 3 line level devices.

Control your ELA speakers conveniently via the 6 zone outputs of the MPZ-250.6. They can be switched separately on the front panel. For you, this means the greatest possible adaptability when implementing your sound reinforcement concept.


Make yourself heard!

The microphone input at the front has an adjustable priority switch. It allows you to make important announcements with automatic, continuously adjustable level reduction of all signals. You can also use the gong to draw attention to your announcement.

Protective functions

A fan protects the interior of your MPZ-250.6 from overheating. In addition to a switch-on delay, it has protection circuits against overvoltage and short-circuits. In these cases, your loudspeakers are electrically isolated from the amplifier. This protects both the MPZ-250.6 and your speakers from damage.
Features
  • Comfortable control of PA speakers via 6-zone technology
  • 6 PA zone outputs, independently switchable on the front panel
  • Master PA output (70 V and 100 V)
  • Output for low-impedance speakers (4-16 ohms)
  • 2 rear microphone inputs (6.3 mm jack, unbal.)
  • 1 front microphone input (combination XLR/6.3 mm jack, unbal.) with adjustable priority circuit
  • All microphone inputs with separate level controls
  • 3 line inputs (stereo RCA) with separate level controls
  • 1 line output (stereo RCA)
  • Chime, switchable
  • Treble and bass control for the output signal
  • 7-fold LED level display
  • Master control for the output signal
  • Fan-cooled
  • Protection circuits with LED indication: over current, short circuit, turn-on delay
  • Rack installation, brackets detachable
  • Master Equalizer: 1 x 2 band tone control Mono
Technical specifications
Power supply:230 V AC, 50 Hz
Output type:70 V, 100 V or 4-16 ohms
Output current:3.6 A (70 V), 2.5 A (100 V)
Mic inputs:5 mV, 600 ohms
Line inputs:300 mV, 10 kohms
Speaker connectors:Screw connectors, terminal block
Distortion:0.5 % (1 kHz)
S/N ratio:85 dB (line), 75 dB (mic)
Weight:14 kg
Power consumption:500.00 W
Output power:250 W RMS
Frequency range:80 - 16000 Hz
Height:8,9 cm
Depths:38,5 cm
Width:48,3 cm
Packaging units
PU EAN Weight Dimensions
1 4026397422207 13,45 kg 55,5cm x 48,5cm x 18,5cm
