PA mono mixing amplifier with audio player and Bluetooth, 120 watts
OMNITRONIC CP-120P PA Mixing Amplifier

svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
svg
OMNITRONIC

PA mono mixing amplifier with audio player and Bluetooth, 120 watts

OMNITRONIC CP-120P PA Mixing Amplifier

Item no. 80709603

Omnitronic CP series - very compact mixers for public address systems (100 V)
The PA mono mixing amplifiers of the CP series have been specially designed for the use in 100 V PA systems. They supply an output power of 30, 60 or 120 watts. PA speakers with 70 V and 100 V audio transformers or low-impedance speakers can be connected.

It is possible to connect microphones and units with line level to the six inputs which can be mixed with each other. Microphone channel 1 is equipped with a priority function which reduces the volume of the other signal sources in case of an announcement. Additional input and output terminals connect a telephone system allowing you to make important announcements and to play music for people waiting to be answered.

The PA amplifiers are equipped with an audio player with Bluetooth receiver, USB port, SD card slot, and FM tuner with auto scan. An IR remote control is included for convenient control of the audio player.
Features

PA mono mixing amplifier with audio player and Bluetooth, 120 watts

  • Compact PA mono mixing amplifier 1 x 30 W (CP-30P), 1 x 60 W (CP-60P), 1 x 120 W (CP-120P)
  • Built-in audio player with Bluetooth receiver and IR remote control
  • Stream music wirelessly from your mobile devices (e.g. smartphone, tablet) via Bluetooth
  • SD card slot and USB input
  • FM tuner with auto scan
  • 3 microphone inputs with separate level controls
  • Mic 1 (XLR) with phantom power and priority circuit
  • Mic 2 and 3 (jack) switchable mic/line
  • 2 aux inputs (RCA) with separate level controls
  • 1 telephone input with priority and MOH circuit (Music on Hold) for telephone systems with audio output
  • 1 line output (RCA)
  • Treble and bass and master controls for the output signal
  • 4-fold LED level display
  • Protection circuits with LED indication: overload, short circuit, clip limiter, overheat
  • Compact desktop console

Audio player

  • Control: Bluetooth built-in; IR remote control included
Technical specifications
Power supply:230 V AC, 50 Hz
or
24 V DC
Power consumption:175 W
Output power:120 W RMS
Power connection:Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
Mains input screw terminal possible
Frequency range:60 - 15000 Hz
S/N ratio:>75 dB Microphone; >85 dB line
Impedance:4 Ohm; 8 Ohm; 16 Ohm; 100 V ELA
Master equalizer:1 x 2-band tone control Mono
Circuitry:Class D
Connections:Input: 1 x Microphone via 3-pin XLR
Input: 2 x mic/line via 6.3 mm jack socket (stereo) mounting version
Input: 2 x line via Stereo RCA
Input: TEL via screw terminal 0,1 V
Output: 1 x line via Stereo RCA 0,774 V
Output: Speakers via screw terminal
Output: MOH via screw terminal 1 V
Distortion:<0,5 %
Material:Metal
Width:32 cm
Height:9,3 cm
Depth:23,8 cm
Weight:5,00 kg
Audio player
Control:Bluetooth built-in
IR remote control included
Audio player:USB + SD + Bluetooth + FM Radio
Format:MP3
Frequency band:2.4 GHz
Range:10 m Bluetooth
Remote control
Power supply:3 V DC
Power connection:Battery/battery pack built-in
Battery:1 x Button cell 3.0 V CR2025 lithium manganese built-in
Packaging units
PU EAN Weight Dimensions
1 4026397614770 5,65 kg 40cm x 31cm x 17cm
2 4026397617573 12,10 kg 41cm x 32cm x 36cm
