Compact DMX converter for LED pixel strips
EUROLITE DXT DMX Pixel Converter PRO, male connector

2 cm

Compact DMX converter for LED pixel strips

EUROLITE DXT DMX Pixel Converter PRO, male connector

Stock for approx. 12 wk(s)
add to cart
Find a dealer
List price excl. 19% VAT
Prices in retail stores may vary.
Item no. 70064856

Compact DMX converter for LED pixel strips

  • Can control up to 18,000 digital LED pixels via a DMX512 signal
  • Extremely compact design placed in the XLR plug
  • 1 x 4-pin JST connector (male) with Data and Clock output
  • 1 x 3-pin JST connector (male) with Data output
  • Multiple LEDs can be grouped together to form virtual pixels, e.g. a strip with 300 LEDs can be controlled with 3 DMX channels
  • 1 to 6 colors per pixel
  • Refresh rate: DMX, 40 Hz, 20 Hz, 10 Hz, 5 Hz
  • Does not require a separate adapter - power supply is via LED strip (5-12 V)
  • Mounting via supplied plastic clip
  • Configuration via software tool (Windows) and the Eurolite USB-DMX adapter (item 51860118)
  • The "Pixel Converter Config Tool" is available for download from the product page at
  • Made in Germany
Technical specifications
Power supply:5-12 V DC 20 mA
Dimensions:Length: 7,5 cm
Diameter: Ø 2 cm
Weight:40 g
Packaging units
PU EAN Weight Dimensions
1 4026397691917 0,22 kg 33cm x 24cm x 6cm
