Spotlight bar with 4 LED heads, LEDs in RGBAW and DMX
EUROLITE LED QDF-Bar RGBAW Light Set

svg
svg
svg
svg
svg
svg
svg
EUROLITE

Spotlight bar with 4 LED heads, LEDs in RGBAW and DMX

EUROLITE LED QDF-Bar RGBAW Light Set

Stock for approx. 12 wk(s)
179,00
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 51918574

Features

Spotlight bar with 4 LED heads, LEDs in RGBAW and DMX

  • Crossbar with integrated DMX control unit and stand sleeve
  • Ultra-light ideally suited for mobile use
  • Ideal for bands, stages or solo entertainers
  • Suited for installation on a speaker stand (not included) or truss
  • Comes pre-assembled with practical transport bag
  • Equipped with 240 LEDs (5 mm) in the colors red, green, blue, amber and white
  • Movable and tiltable spotlights
  • Via DMX, each spot can be individually controlled
  • DMX-controlled operation or stand-alone operation
  • Sound-control via built-in microphone, microphone sensitivity adjustable
  • DMX512 control via any commercial DMX controller (occupies 23 channels)
  • 4, 7 or 23 DMX channels selectable
  • Functions: Effect/color presets, built-in programs, strobe effect with variable speed, sound-control, Master/Slave operation
  • Addressing and setting via control panel with 4-digit LED display
  • Additional controlling possibility via the EUROLITE IR-7 remote control, included in delivery
  • Black lacquered metal version
  • IEC terminals for power linking up to 8 units
  • Switch-mode power supply for operation between 100 and 240 volts
  • LED: 240 x 5 mm RGBWA
  • Control: IR remote control; Stand-alone; Sound to light via Microphone; DMX
  • Projection: flicker-free
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
Power consumption:20 W
IP classification:IP20
Power connection:Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
Power output:1 x IEC connector (F) mounting version
Fuse:F fast-blow, 1 A Fuse replaceable
LED:240 x 5 mm RGBWA
Flash rate:0 - 20 Hz
DMX channels:4; 7; 23
DMX input:1 x 3-pin XLR (M) mounting version
DMX output:1 x 3-pin XLR (F) mounting version
Cooling fan:No, cooling by convection
Control:IR remote control
Stand-alone
Sound to light via Microphone
DMX
Housing color:Black
Width:85 cm
Height:36 cm
Depth:11 cm
Weight:4,5 kg
Remote control
Battery:1 x Button cell 3.0 V CR2025 lithium manganese built-in
Legal specifications
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
Packaging units
PU EAN Weight Dimensions
1 4026397604245 6,40 kg 89cm x 16cm x 44cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
51918574-Manual-128451-1.100-de_en.pdf (4 MB) 1.100 de_en
All images
Name Version Language
51918574-Images.zip
Publications
publicationImage
main catalog 2019 St. E #28
On page: 128
Size: 284 MB
