Compact beam effect with beams in 6 colors (RGBWA+UV)
EUROLITE LED Z-20 Beam Effect

Name: EUROLITE LED Z-20 Beam Effect
Uploaded: 2022-01-01
Description: Compact beam effect with beams in 6 colors (RGBWA+UV)

Compact beam effect with beams in 6 colors (RGBWA+UV)-MainBild

28 cm

Compact beam effect with beams in 6 colors (RGBWA+UV)

EUROLITE LED Z-20 Beam Effect

Stock for approx. 12 wk(s)

99,00 €

List price excl. 19% VAT
Prices in retail stores may vary.

No. 51918524

Print product

Product badge

Here you find the manual and downloads for
EUROLITE LED Z-20 Beam Effect

5 colors plus blacklight

The LED Z-20 by Eurolite is a classic mushroom beam effect with six different 3-watt LEDs that produce mesmerizing light shows in the colors red, green, blue, amber, white, and including UV light.

Various control options

The device works with preset programs which can be played either fully automatically in automatic mode or sound-controlled via the integrated microphone. The emanating beams then move in circles and change their direction with each bass beat. Changing color patterns, strobe effects and the adjustable running speed and microphone sensitivity complete the package.

Everywhere in use

Of course, the LED Z-20 is delivered ready to use with plug and power cord. With a low power consumption of 16 watts and only 2 kg weight, the LED Z-20 is an exciting, inexpensive beam effect for mobile DJs, clubs, bars and party rooms of any kind.

Features

Compact beam effect with beams in 6 colors (RGBWA+UV)

Beams exit from every lens, perform circular movements and change the direction of movement with every bass-beat
When using smoke, the brilliant colors are especially rich
6 powerful LEDs 3 W high-power R/G/B/W/A/UV
Program speed adjustable; color macros changing
Multi beam effect; flower effect; strobe effect
The device is cooled by passive convection cooling
Control via stand-alone; sound to light via microphone
With mounting bracket
For application areas such as: Party room; small rental
Very quiet working noise
Application possibility: Suspended; on stand

Package contents

1 x device, 1 x mounting bracket, 1 x user manual, 1 x power cord

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	16 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug included
Fuse:	5 x 20 mm, F 0,5 A fuse replaceable
Lamp type:	LED lamp
LED type:	6 x 3 W high-power R/G/B/W/A/UV
Cooling:	Passive convection cooling
Control:	Stand-alone; sound to light via microphone
Housing color:	Black matte
Attachment system:	Mounting bracket
Dimensions:	Length: 31 cm Diameter: Ø 28 cm
Weight:	2,20 kg
Noise classification:	Class 1 (very slight noise, suitable for noise-sensitive environments)
Mounting bracket
Diameter mounting holes:	1 x Ø11mm
Material:	Metal, 2 mm
Power cord
Cable construction:	3 x 0,75 mm² H05VV-F
Cable length:	Approx. 1,2 m
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397526653	2,80 kg	32cm x 31,5cm x 35cm
4	4026397526660	12,65 kg	64cm x 65,5cm x 38cm
