Variable truss light and uplight with bright 4 x 8 W RGB+UV LED
EUROLITE LED TL-4 QCL RGB+UV Trusslight

Name: EUROLITE LED TL-4 QCL RGB+UV Trusslight
Brand: EUROLITE

13°

Stock for approx. 12 wk(s)

79,90 €

Find a dealer

Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Save money: This article is available in a bundle.

Sets are loaded. Please wait...

Features

Variable truss light and uplight with bright 4 x 8 W RGB+UV LED

Compact and bright, making it perfect for truss installation
Equipped with 4 x 8 W 4in1 LED in the colors red, green, blue and UV
DMX-controlled operation or stand-alone operation with Master/Slave function
3, 4-1, 4 or 8 DMX channels selectable
Built-in auto and music show programs
Direct color selection for 18 preset colors
Functions: static colors, stepless RGB+UV color mixture, internal programs, dimmer, strobe effect with variable speed, sound-control, Master/Slave operation
Sound-control via built-in microphone with adjustable microphone sensitivity
Flicker-free projection
Supports QuickDMX - the wireless DMX system from Eurolite
Built-in phantom-powered USB port for QuickDMX receivers (accessories)
DMX control via any standard DMX controller
Addressing via control panel with 4-digit LED display
Convenient wireless control via included IR remote control EUROLITE IR-7
Ideal for booth construction, stages and anywhere trussing is used
Perfect for ALUTRUSS 4-POINT SYSTEM QUADLOCK
Hanging as well as standing installation possible
M10 threaded insert for suspended installation
Folding foot adjustable in 5 steps for flexible placement
Additional rubber feet when the spot shall be positioned on the floor
Ready for connection via included power cable with safety power plug
Feed-through output allows to power up to 8 devices
LED: 4 x high-power 8 W 4in1 QCL RGB/UV (homogenous color mix)
Control: QuickDMX viaUSB (optional); IR remote control included; Sound to light viaMicrophone; DMX

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	15 W
LED:	4 x high-power 8 W 4in1 QCL RGB/UV (homogenous color mix)
Flash rate:	0 - 20 Hz
DMX channels:	3; 4; 4; 8
DMX input:	1 x USB, type A
	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
IP classification:	IP20
Cooling fan:	No, cooling by convection
Control:	QuickDMX via USB (optional)
	IR remote control included
	Sound to light via Microphone
	DMX
Beam angle:	13°
Case color:	Black
Length:	15,5 cm
Width:	14,5 cm
Height:	13,0 cm
Weight:	1,56 kg
Legal specifications
Ecodesign regulation:	Yes
Special product:	Not designed for household room illumination
Purpose:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397658286	1,70 kg	18cm x 18cm x 16cm
8	4026397658811	14,25 kg	38cm x 37,5cm x 34,5cm
