60 W beam, compact, RGBW color mixing, large zoom, 8-facet prism
EUROLITE LED TMH-X3 Moving Head Beam

EUROLITE

60 W beam, compact, RGBW color mixing, large zoom, 8-facet prism

EUROLITE LED TMH-X3 Moving Head Beam

Stock for approx. 12 wk(s)
499,00
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 51785989

Features
  • Equipped with a 60 W LED with RGBW colors from Osram
  • Motorized zoom with 5-47° radiation angle
  • Effect wheel with rotating 8-facet prism
  • Positioning within 540° PAN and 220° TILT
  • PAN angle switchable between 360° and 540°
  • Compact lightweight
  • Stepless RGBW color mixture
  • Masterdimmer
  • Internal programs
  • Sound-controlled via built-in microphone
  • Color change
  • Strobe effect with adjustable speed
  • Automatic position correction
  • Exact positioning via 16 bit PAN/TILT movement resolution
  • DMX-controlled operation or stand-alone operation with Master/Slave function
  • Control board with LCD for adjusting the DMX-starting address, PAN/TILT Reverse, Reset
  • Switch-mode power supply for operation between 100 and 240 volts
  • Power connection via P-Con jack and included power cable with safety plug
  • Feed-through output allows to power up to 8 devices
  • DMX control via every standard DMX controller
  • Effect: Single Beam
  • Projection: flickerfree
  • Equipment: Prisma 8-fold; Zoom motor-driven
  • Power out: 1 x P-Con (Power-out)
  • Power supply of device: Mains Input Socket (M) P-Con (Power-In) fehlt provided
  • Control: DMX; Stand-alone
  • LED: 1 x COB chip-on-board 60 W 4in1 QCL RGBW Homogenous colormix
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
DMX channels:16
DMX connection:3-pin XLR
Flash-rate:18 Hz
Sound-control:via built-in microphone
LED number:1
LED type:60 W RGBW
Beam angle:5-47°
Maximum PAN-movement:540°
Maximum TILT-movement:220°
Dimensions (L x W x H):190 x 245 x 370 mm
Lamp type:LED lamp
Weight:6 kg
Cooling fan:Yes
IP classification:IP20
Power consumption:90 W
Laser class:Without laser
Beam angle:5 - 47°
Height:37 cm
Depth:19 cm
Width:24,5 cm
Max. TILT movement:Exact positioning (16 bit resolution) 220° Pan tilt feedback
DMX channels:16
Max. PAN movement:Exact positioning (16 bit resolution) 540° Positioning switchable to 360° Pan tilt feedback
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
Packaging units
PU EAN Weight Dimensions
1 4026397594089 7,40 kg 31cm x 26cm x 45cm
2 4026397594096 15,85 kg 54cm x 33cm x 47,5cm
