Powerful QCL Moving Head with a 10 W CREE quadcolor LED with RGBW colors
EUROLITE LED TMH-8 Moving Head Spot

svg
svg
svg
svg
svg
svg
13°
svg
svg
EUROLITE

Powerful QCL Moving Head with a 10 W CREE quadcolor LED with RGBW colors

EUROLITE LED TMH-8 Moving Head Spot

Item no. 51785963

TMH-8

Powerful & compact spotlight

A small, light and yet powerful spotlight. The TMH-8 weighs about 3 kg, has 9 gobos (plus open), a goboshake function, a rainbow effect and stepless color mixing. Inside the device, a CREE Quadcolor LED (RGBW) beats with 10 watts.
Features

Powerful QCL Moving Head with a 10 W CREE quadcolor LED with RGBW colors

  • Equipped with a 10 W CREE quadcolor LED with RGBW colors
  • Compact lightweight
  • 14 or 5 DMX channels selectable for numerous applications
  • Positioning within 540° PAN and 230° TILT
  • Stepless RGBW color mixture
  • Color-macro-function for an easy selection of possible color-combinations
  • Gobo-wheel with 9 static gobos plus open
  • With gobo-shake function
  • Rainbow-effect with adjustable speed
  • Programmable color-change speed and strobe effect
  • Strobe effect with 1-10 flashes per second
  • Exact positioning via 16 bit PAN/TILT movement resolution
  • PAN-angle switchable between 540°, 360° and 180° (in sound and auto mode)
  • TILT-angle switchable between 230°, 180° and 90° (in sound and auto mode)
  • DMX-controlled operation or stand-alone operation with Master/Slave function
  • 8 motion macros can be called up via DMX controller
  • Sound-control via built-in microphone
  • Addressing via control panel with 4-digit LED display
  • DMX control via every standard DMX controller
  • LED: 1 x SMD 10 W 4in1 QCL RGBW (homogenous color mix)
  • Control: Sound to light via Microphone; Sound to light via Microphone; Stand-alone; DMX
  • Effect: Gobo effect; Single Beam
Technical specifications
Power supply:230 V AC, 50 Hz
Power consumption:35 W
IP classification:IP20
Power connection:Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
LED:1 x SMD 10 W 4in1 QCL RGBW (homogenous color mix)
Max. TILT movement:Exact positioning (16 bit resolution) 230° Positioning switchable to 180° and 90°
Max. PAN movement:Exact positioning (16 bit resolution) 540° Positioning switchable to 360° and 180°
Flash rate:1 - 10 Hz
Equipment:Gobos; Color wheel
Gobos:Gobo wheel with static gobos, 9 gobos and open
Shake effect
DMX channels:14; 5
DMX input:1 x 3-pin XLR (M) mounting version
DMX output:1 x 3-pin XLR (F) mounting version
Cooling:Cooling fan
Control:Sound to light via Microphone
Sound to light via Microphone
Stand-alone
DMX
Beam angle:13°
Beam angle (1/2 peak):13°
Housing color:Black
Width:17 cm
Height:24.5 cm
Depth:17.5 cm
Weight:3.20 kg
Legal specifications
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
Packaging units
PU EAN Weight Dimensions
1 4026397441673 3,60 kg 27cm x 22cm x 26cm
2 4026397441680 8,00 kg 46cm x 29,5cm x 29cm
