Compact LED moving head wash with 120 W RGB/WW LED and backlighting via RGB hypno LEDs
EUROLITE LED TMH-W120 Hypno Moving Head Wash

svg
svg
svg
svg
svg
svg
svg
svg
11°
svg
svg
svg
svg
svg
svg
EUROLITE

Compact LED moving head wash with 120 W RGB/WW LED and backlighting via RGB hypno LEDs

EUROLITE LED TMH-W120 Hypno Moving Head Wash

Stock for approx. 12 wk(s)
299,00
add to cart
List price excl. 19% VAT
Prices in retail stores may vary.
No. 51785928
Features

Compact LED moving head wash with 120 W RGB/WW LED and backlighting via RGB hypno LEDs

  • 1 powerful LED 120 W COB (chip-on-board) 4in1 QCL RGB/WW (homogenous color mix)
  • 26 powerful LEDs 0,2 W SMD 5050 3in1 TCL RGB (homogenous color mix)
  • Positioning within 540° PAN, 200° TILT
  • Exact positioning (16 bit resolution)
  • Dimmer; dimmer curves adjustable
  • Wash effect
  • The device is cooled by temperature-controlled fan at the Head; low-noise cooling fan at the base
  • Control via stand-alone; sound to light via microphone; DMX; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); W-DMX by wireless solution via USB (optional); master/slave function
  • Flicker-free
  • DMX fail mode (hold; zero values)
  • With a beam angle of 11°
  • With omega bracket
  • 4 digit 7-segment LED display
  • 4 rubber feet
  • Mains input and output for power linking up to 8 units

Package contents

  • 1 x moving light, 1 x user manual, 1 x power cord, 1 x omega bracket
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
Power consumption:130 W
IP classification:IP20
Protection class:Protection class I
Power connection:Mains input via P-Con (blue), mounting version power supply cord with safety plug
Power output:P-Con (gray), mounting version
Fuse:5 x 20 mm, T 2 A fuse replaceable
Lamp type:LED lamp
LED type:1 x 120 W COB (chip-on-board) 4in1 QCL RGB/WW (homogenous color mix)
26 x 0,2 W SMD 5050 3in1 TCL RGB (homogenous color mix)
Max. TILT movement:200° exact positioning (16 bit resolution)
Max. PAN movement:540° exact positioning (16 bit resolution)
Flash rate:1 - 20 Hz
DMX channels:23
DMX input:3-pin XLR (M) mounting version
DMX output:3-pin XLR (F) mounting version
Cooling:1 x temperature-controlled fan at the Head
1 x low-noise cooling fan at the base
Control:Stand-alone; sound to light via microphone; DMX; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); W-DMX by wireless solution via USB (optional); master/slave function
Projection:Flicker-free
PWM frequency:20000 Hz
DMX fail mode:Hold; zero values
Beam angle:11°
Beam angle (1/2 peak):11°
Beam angle (1/10 peak):20°
Illuminance in Lux (lx):Red (R) 1m: 11680 lx, 3m: 1064 lx, 6m: 257 lx
Green (G) 1m: 21059 lx, 3m: 1883 lx, 6m: 429 lx
Blue (B) 1m: 4476 lx, 3m: 434 lx, 6m: 102 lx
Warm white (WW) 1m: 19730 lx, 3m: 1711 lx, 6m: 408 lx
All 1m: 52623 lx, 3m: 4746 lx, 6m: 1108 lx
Housing color:Black
Attachment system:Omega bracket
Display type:4 digit 7-segment LED display
USB port:Type A
Transport aid:4 x rubber feet
Diameter mounting holes:1 x Ø10mm
Material:Plastic
Dimensions:Width: 20 cm
Depth: 14 cm
Height: 29 cm
Weight:3,60 kg
Legal specifications
Special product:Not designed for household room illumination
Intended use:Show effect lighting
Packaging units
PUEANWeightDimensions
140263977401104,00 kg31cm x 26cm x 22,5cm
4402639774389016,70 kg53cm x 32cm x 47,5cm
