Spotlight with 5 effects: flower, wash, UV, 2 lasers (2M), strobe
EUROLITE LED Penta FX Hybrid Laser Effect

Name: EUROLITE LED Penta FX Hybrid Laser Effect
Brand: EUROLITE
SKU: 51741073
Price: 199.00 EUR
Availability: InStock

Stock for approx. 12 wk(s)

199,00 €

Find a dealer

Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Features

Spotlight with 5 effects: flower, wash, UV, 2 lasers (2M), strobe

5in1 LED effect light with IR remote control
Washlight and blacklight with 9 x RGB+UV LEDs
2 laser diodes project thousands of red and green laser beams
A total of 84 RGBA LEDs for amazing flower effects
Stroboscope with 12 ultra-bright white LEDs
All effects can be controlled individually
Built-in auto and music show programs
Laser class 2M: does not require additional protective measures or appointment of a laser safety officer
Auto, music, master/slave and DMX mode
Convenient wireless control via included IR remote control
Addressing and setting via control panel with 4-digit LED display
Sound-control via built-in microphone with sensitivity control
Mounting bracket for flexible wall mounting and ceiling suspension
When fog is used, this effect becomes especially attractive
IEC terminals for power linking up to 8 units
Switch-mode power supply for operation between 100 and 240 volts
Control: IR remote control; Stand-alone; Sound to light via Microphone; DMX
Effect: Multi beam effect; Flower effect; Strobe effect; UV

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	90 W
IP classification:	IP20
Power connection:	Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
Power output:	1 x IEC connector (F) mounting version
LED:	Strobe effect 12 x SMD 0,5 W CW (homogenous color mix)
	Multi beam effect 84 x high-power 0,75 W RGBA
	UV effect 9 x high-power 4 W 4in1 QCL RGB/UV (homogenous color mix)
Laser class:	Class 2M
Laser module:	R red 100 mW 650nm
	G green 30 mW 532nm
DMX channels:	3; 5; 11; 28
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Cooling fan:	Yes
Control:	IR remote control
	Stand-alone
	Sound to light via Microphone
	DMX
Housing color:	Black
Width:	33,5 cm
Height:	31,2 cm
Depth:	19,1 cm
Weight:	3,25 kg
Remote control
Battery:	1 x Button cell 3.0 V CR2025 lithium manganese built-in

Packaging units

PU	EAN	Weight	Dimensions
1	4026397611397	3,80 kg	39cm x 35cm x 20,5cm
4	4026397611403	16,05 kg	72cm x 40,5cm x 44cm
