Technical specifications

Power supply:	230 V AC, 50 Hz
Power consumption:	1500 W
IP classification:	IP63
Power connection:	Fixed power supply cord with safety plug
Warm-up time:	Approx. 10 min
Output distance:	Approx. 6 m
Tank capacity:	Water-based fluid external tank
Fluid consumption:	Approx. 90 ml/min
DMX channels:	1
DMX input:	1 x 5-pin XLR (M) mounting version
Control:	Stand-alone; DMX; wireless remote control
Carrier frequency:	433.920 MHz
Housing color:	Grey
Attachment system:	Mounting bracket
Display type:	Monochrome LCD display
Controls:	Low fluid
Color:	Grey
Dimensions:	Width: 24.9 cm Depth: 14.7 cm Height: 35.5 cm
Weight:	12.60 kg
Remote control
Battery:	1 x 12 V LR27 alkaline manganese built-in
Range:	Range up to 50m

Packaging units

PU	EAN	Weight	Dimensions
1	4719850651404	14,00 kg	59cm x 34,5cm x 33cm
1	4026397494617	14,00 kg	59cm x 34,5cm x 33cm

Spare parts

ANTARI W-1 Wireless Controller

Receiver IP-1500

Pcb (Liquid sensor) IP-1500

Heating element 1500W IP-1500

Pcb (Display) IP-1500 (B06659 REV.2)

Pcb (Control) IP-1500 (B06507V5)

Pump Z MK2 series (SP-35A M24070) (PEOEX7A10)

Thermostat 220°C K-25

housing part (Fluid sensor) IP-1500 white

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
51702815-Images-.zip

ANTARI IP-1500 Fog Machine IP63

1500-watt outdoor fogger (IP63) with wireless control and DMX-MainBild

1500-watt outdoor fogger (IP63) with wireless control and DMX-Bild-1

ANTARI IP-1500 Fog Machine IP63

The article is no longer in our assortment.

Check out the alternatives:

Spray water protected 1000 W machine with cable remote control

ANTARI IP-1000 Fog Machine IP63

this alternative has a lower power

No. 51702805

Stock for approx. 12 wk(s)

539,00 €

1500-watt outdoor fogger (IP64) with wireless control and DMX

ANTARI IP-1600 Fog Machine

interesting alternative, take a look!

No. 51702816

Stock for approx. 12 wk(s)

1.199,00 €

ANTARI IP-3000 Fog Machine

interesting alternative, take a look!

No. 51702817

Stock for approx. 12 wk(s)

1.349,00 €

No. 51702815

1500-watt outdoor fogger (IP63) with wireless control and DMX

Efficient heat exchanger achieves 13 % less electricity consumption than comparable fog machines and ensures low fluid consumption, making the IP-1500 the greenest choice
Automatic adjustment of operating parameters during outdoor use
Adjustable timer with interval, duration and output volume
Continuous output with adjustable snow volume or manual activation with maximum snow volume
The transmitter allows simultaneous control of an unlimited number of machines
Designed without tank for highest flexibility and continuous operation: the fog fluid is supplied via the included tube from an external tank (not included)
Output distance: Approx. 6 m
Operates on water-based fluid
Control via stand-alone; DMX; wireless remote control
With mounting bracket
Monochrome LCD display
Suitable for outdoor use IP63

remote control

Operating range up to 50m
