LED Barrel, unlimited PAN/TILT movement, 15 W LEDs in RGBW
EUROLITE LED MFX-8 Action Barrel

svg
svg
svg
svg
svg
svg
svg
EUROLITE

LED Barrel, unlimited PAN/TILT movement, 15 W LEDs in RGBW

EUROLITE LED MFX-8 Action Barrel

Stock for approx. 12 wk(s)
349,00 €
251,26
-28% valid until 31.12.2020
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 50944323

Features

LED Barrel, unlimited PAN/TILT movement, 15 W LEDs in RGBW

  • Beam effect with 9 lenses with 10 W quadcolor LEDs in RGBW colors arranged in 3 rows
  • Compact lightweight
  • With Infinity function for unlimited TILT movement
  • Positioning within 630° PAN and 200° TILT
  • PAN-angle switchable between 630° and 540°
  • Functions: Colored beams, auto mode, sound control, color presets, color change, Master/Slave function, built-in programs, stepless RGBW color mixture - each LED row can be controlled individually
  • Masterdimmer
  • Strobe effect with 1-25 flashes per second and with adjustable speed
  • Random strobe effect
  • Automatic position correction
  • Exact positioning via 16 bit PAN/TILT movement resolution
  • DMX-controlled operation or stand-alone operation with Master/Slave function
  • Sound-controlled via built-in microphone, sensitivity adjustable
  • Addressing via control panel with 4-digit LED display
  • Switch-mode power supply for operation between 100 and 240 volts
  • Ready for connection with power cord and safety plug
  • LED: 9 x high-power 10 W 4in1 QCL RGBW
  • Can be operated in 12; 22 CH mode
  • Control: DMX; Sound to light via Microphone; Stand-alone
  • Flicker-free projection
  • Effect: Multi beam effect
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
Power consumption:130 W
IP classification:IP20
Power connection:Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
LED:9 x high-power 10 W 4in1 QCL RGBW
Max. TILT movement:Exact positioning (16 bit resolution) 200° plus infinity Auto position correction (feedback)
Max. PAN movement:Exact positioning (16 bit resolution) 540° Positioning switchable to 630° Auto position correction (feedback)
Flash rate:0 - 25 Hz
DMX channels:12; 22
DMX input:1 x 3-pin XLR (M) mounting version
DMX output:1 x 3-pin XLR (F) mounting version
Control:DMX
Sound to light via Microphone
Stand-alone
Beam angle:
Beam angle (1/2 peak):
Housing color:Black
Width:25.5 cm
Height:32.5 cm
Depth:13.5 cm
Weight:5.95 kg
Legal specifications
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
Packaging units
PU EAN Weight Dimensions
1 4026397592733 6,65 kg 39cm x 32cm x 21cm
2 4026397598841 14,10 kg 40cm x 34cm x 45cm
