Moving Effect with 6 light beams and Mood Light Strips on the edges
EUROLITE LED MFX-3 Action Cube

EUROLITE

Moving Effect with 6 light beams and Mood Light Strips on the edges

EUROLITE LED MFX-3 Action Cube

Stock for approx. 12 wk(s)
389,00
add to cart
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 50944303

Features
  • Beam effect with 6 lenses and 10 W quadcolor LEDs in RGBW colors and 12 LED mood light strips with 4 RGB SMD LEDs each
  • Compact lightweight
  • With infinity function for unlimited TILT movement
  • Positioning within 630° PAN and 200° TILT
  • PAN-angle switchable between 630° and 540°
  • 14 or 16 DMX channels selectable
  • Flicker-free projection
  • Functions: Colored beams, LED mood light strips, auto mode, sound control, color presets, color change, Master/Slave function, built-in programs, stepless RGBW color mixture
  • Masterdimmer
  • Strobe effect with 1-25 flashes per second and with adjustable speed
  • Random strobe effect
  • Automatic position correction
  • Exact positioning via 16 bit PAN/TILT movement resolution
  • DMX-controlled operation or stand-alone operation with Master/Slave function
  • Sound-controlled via built-in microphone, sensitivity adjustable
  • Addressing via control panel with 4-digit LED display
  • Switch-mode power supply for operation between 100 and 240 volts
  • Ready for connection with power cord and safety plug
  • DMX512 control via every standard DMX controller
  • Color generation: RGBW
  • Color generation: RGB
Technical specifications
Power supply:100-240 V AC, 50/60 Hz
DMX channels:14/16
DMX connection:3-pin XLR
Sound-control:via built-in microphone
Flash-rate:25 Hz
LED number:6 x QCL + 48 x SMD
LED type:10 W QCL, RGBW + RGB SMD
Maximum PAN-movement:630°
Maximum TILT-movement:unlimited
Dimensions (L x W x H):250 x 180 x 350 mm
Lamp type:LED lamp
Weight:5 kg
IP classification:IP20
Power consumption:75 W
Laser class:Without laser
Beam angle:9 °
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
Packaging units
PU EAN Weight Dimensions
1 4026397576443 6,35 kg 42cm x 34cm x 27cm
2 4026397578997 13,90 kg 57cm x 36cm x 44cm
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
00098917.pdf 1.00 en/de
Support
Name Version Language
50944303 LED PC Control fixtures
00105536.zip
1.00 de
Catalog pages
Name Version Language
00115112.pdf 27.00 de
00115549.pdf 27.00 en
Press report
Video file
Name Version Language
00100585.flv 0.00 es/fr/en/de
All images
Name Version Language
50944303.zip
