Technical specifications

Power supply:	12/24V DC
Power consumption:	Max. 384 W 12 V DC Max. 768 W 24 V DC Max. 96 W 12 V DC per channal Max. 192 W 24 V DC per channal
Output current:	Max. 4 x 8 A per channal
Power connection:	Via screw terminal
Power output:	Screw terminal
DMX channels:	4
DMX input:	3-pin XLR (M) mounting version 1 x RJ-45 (F) mounting version
DMX output:	3-pin XLR (F) mounting version RJ-45 (F) mounting version
Control:	Stand-alone
Dimensions:	Length: 16.4 cm Width: 6.6 cm Height: 3.8 cm
Weight:	0.30 kg
Noise classification:	Class 0 (no noise at all)

Packaging units

PU	EAN	Weight	Dimensions
1	4026397637441	0,33 kg	18cm x 8cm x 6cm
50	4026397637458	17,55 kg	44cm x 40cm x 33cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Support

Name	Version	Language
50531100-Support-120323-1.0000-LED-Strip-DMX-Controller-LED-PC-Con-de.zip (699 B)	1.0000	de

All images

Name	Version	Language
50531100-Images-.zip

EUROLITE LED Strip RGBW 4-channel DMX Controller

Name: EUROLITE LED Strip RGBW 4-channel DMX Controller
Brand: EUROLITE
SKU: 50531100
Price: 44.90 EUR
Availability: InStock

Stock for approx. 12 wk(s)

44,90 €

Find a dealer

Stock for approx. 12 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 50531100

4-channel LED controller with DMX interface for RGB LEDs 12-24 V

Compact LED controller for controlling RGBW LEDs (12-24 V) via DMX
Converts standard DMX512 signals to PWM signals e.g. for driving LED strips
4 separate control channels for individual color mixing of red, green, blue and white LEDs
Switchable termination resistor
Plug-in screw terminals for connecting the LEDs and the power supply
RJ45 jacks for serial connection
Rugged black metal housing
Integrated show programs
Can be operated in 4 CH mode
Control via stand-alone
For application areas such as: Clubs/dancing school; Trade fair and shop fitting; installation; restaurants, bars and hotels
Silent operation

Technical specifications
