Mirror ball motor for mirror balls up to 150 cm
EUROLITE MD-3050 Safety Rotary Motor

EUROLITE

Mirror ball motor for mirror balls up to 150 cm

EUROLITE MD-3050 Safety Rotary Motor

Stock for approx. 12 wk(s)
149,00
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 50301540

This solid mirror ball motor with a continuous shaft can carry a load of up to 150 kg. This equals a mirror ball of approximately 150 cm, 12-fold safety margin included. The motor has a speed of 1 RPM (rotations per minute). This creates a peaceful effect, especially when you choose for a pin spot to shine on the mirror ball.

The motor is equipped with a patented mechanical drop protection against unintentional loosening of the axis as well as the required second eyelet for the attachment of the safety chain.
All Eurolite safety motors comply with the safety norm DIN EN ISO 12100 and relevant accident prevention regulations. Each production charge is subject to strict quality control which makes the motor suitable for discotheques and other public events. The MD-3050 is delivered ready to use with safety plug and power cord.
Features

Mirror ball motor for mirror balls up to 150 cm

  • Suitable for driving mirror balls up to a maximum weight of 150 kg
  • This weight corresponds with a diameter of 150 cm for the EUROLITE mirror balls
  • The maximum load always means the mirror ball weight including the mirror ball chain, the safety chain and the fixation material
  • 2 chains and 4 quick links must be ordered separately
  • 1 rotation per minute
  • For professional use, e.g. in discotheques and in public places, the EN DIN 15560 norms have to be considered
  • The motor always has to be installed with a secondary safety attachment
  • Before taking into operation for the first time, the installation has to be approved by an expert
Technical specifications
Power supply:230 V AC, 50 Hz
Power consumption:7 W
Rotation:1 RPM
Maximum load:150 kg
Max. mirror ball diameter:150 cm (EUROLITE)
Width:28 cm
Height:11 cm
Depth:24 cm
Weight:5,40 kg
Packaging units
PU EAN Weight Dimensions
1 4026397382747 6,00 kg 30cm x 26,5cm x 22cm
4 4026397486537
Accessories
Loading accessories. Please wait...
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
50301540-Manual-86080-2.200-en_de.pdf (214 KB) 2.200 en_de
Data sheet
Name Version Language
50301540-Datasheet-52811-1.000-de_en.pdf (52 KB) 1.000 de_en
Service document
Name Version Language
All images
Name Version Language
50301540-Images.zip
Publications
main catalog 2019 St. E #28
On page: 269
Size: 284 MB
