Technical specifications

Power supply:	100-240 V AC, 50/60 Hz 12.6V DC 200 mA
Power consumption:	25 W
Protection class:	Protection class III
Power connection:	Battery/battery pack built-in Mains input via coaxial power connector (M) mounting version
Battery pack type:	1 x lithium ion 11.1 V, 5200 mAh, 57.72 Wh
Battery pack:	Battery operation up to 18h depending on program used Recharging time 3.5h
Lamp type:	LED lamp
LED type:	1 x 15 W SMD 9080 4in1 RGB/WW (homogenous color mix)
Flash rate:	1 - 23 Hz
DMX channels:	3; 4; 6; 8; 11
Cooling:	Passive convection cooling
Control:	IR remote control; stand-alone; sound to light via microphone; QuickDMX; master/slave function; DMX
Fixtures available for:	LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE; Light´J; Light Captain; EASY SHOW 2; EASY SHOW 3
Projection:	Flicker-free
Carrier frequency:	2.4 GHz
Beam angle (1/2 peak):	9°
Beam angle (1/10 peak):	18°
Housing color:	Black
Attachment system:	Mounting bracket
Display type:	Monochrome OLED display
Theft protection:	KENSINGTON LOCK
Dimensions:	Width: 11.1 cm Depth: 7.8 cm Height: 17.5 cm
Weight:	1.35 kg
Noise classification:	Class 0 (no noise at all)
Remote control
Battery:	1 x button cell 3.0 V CR2032 lithium manganese built-in
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397680928	1,70 kg	25cm x 22cm x 15cm
8	4026397681291	14,60 kg	53cm x 45,5cm x 33cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Support

Name	Version	Language
41700060-Support-136576-Fixture-fuer-Colorchief-V2x-de.zip (213 B)	0.0000	de

All images

Name	Version	Language
41700060-Images-.zip

Publications

On page: 25

Size: 16 MB

On page: 33

Size: 56 MB

Video link

EUROLITE AKKU Dot 1 RGB/WW QuickDMX bk

The article is no longer in our assortment.

No. 41700060

9°

Battery-powered pinspot with magnetic base, 15 W 4in1 LED, QuickDMX, frost filter and IR remote control

Integrated QuickDMX transceiver for wireless DMX control
Magnetic base affixes to metal surfaces
Additional frost filter provides a wide, soft and homogeneous light
Cordless, flexible and versatile
Battery operation up to 18h depending on program used
Integrated automatic charging of the battery and status indicator
1 LED 15 W SMD 9080 4in1 RGB/WW (homogenous color mix)
Color blend stepless; color change adjustable; color fade adjustable; Dimmer electronic; white balance adjustable; Dimmer speed (step response) adjustable
Strobe effect
36 integrated show programs
Direct color selection for 15 preset colors
Can be operated in 3; 4; 6; 8; 11 CH mode
The device is cooled by passive convection cooling
Control via IR remote control; stand-alone; sound to light via microphone; QuickDMX; master/slave function; DMX
Flicker-free
With a beam angle of 9°
With mounting bracket
Monochrome OLED display
With a KENSINGTON LOCK theft protection
For application areas such as: Small rental; wedding/gala/events; mobile djs / entertainer
Application possibility: Standing; suspended
Silent operation
