Technical specifications

Power supply:	100-240 V AC, 50/60 Hz 12.6V DC 2500 mA
IP classification:	IP65
Protection class:	Protection class III
Power connection:	Mains input via coaxial power connector (M) mounting version power supply cord with Euro plug (provided) Battery/battery pack
Battery pack type:	2 x lithium ion 11.1 V, 2600 mAh, 28.86 Wh
Battery pack:	Battery operation up to 16h depending on program used Recharging time 4h
Lamp type:	LED lamp
LED type:	3 x 8 W SMD 9080 4in1 QCL RGBW (homogenous color mix)
Flash rate:	1 - 23 Hz
DMX channels:	3; 4; 6; 8; 10
Cooling:	Passive convection cooling
Control:	Master/slave function; IR remote control; QuickDMX; stand-alone; sound to light via microphone
Fixtures available for:	Light´J; Light Captain; EASY SHOW 1; EASY SHOW 2; EASY SHOW 3; Colorchief
Projection:	Flicker-free
Carrier frequency:	2.4 GHz
Beam angle:	15°
Beam angle (1/2 peak):	15°
Beam angle (1/10 peak):	33°
Housing color:	Black
Attachment system:	Mounting bracket
Display type:	LCD display
Dimensions:	Width: 17.2 cm Depth: 13.8 cm Height: 6.2 cm
Weight:	1.61 kg
Noise classification:	Class 0 (no noise at all)
Remote control
Battery:	1 x button cell 3.0 V CR2032 lithium manganese built-in
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397686395	1,90 kg	26,5cm x 20cm x 11cm
8	4026397686401	15,70 kg	56cm x 43cm x 25,5cm

Spare parts

LED QCL 8W RGBW (TX-BRWG2B140)

Pcb (Control/Display) AKKU Flat Light 3 (SL-MAIN-Q3-V01)

Battery 11,1V/2600mAh (18650) AKKU Flat Light 3 (Li-Ion)

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Dimensional drawing

Name	Version	Language
41700020-Dimensions-162570-1.0000-41700020dimensionspdf-de.pdf (83 KB)	1.0000	de

Support

Name	Version	Language
41700020-Support-161415-Fixture-fuer-Colorchief-V2-de.zip (229 B)	0.0000	de

All images

Name	Version	Language
41700020-Images-.zip

Video link

https://www.youtube-nocookie.com/embed/tSS4PThLJs0

EUROLITE AKKU IP Flat Light 3 bk

Name: EUROLITE AKKU IP Flat Light 3 bk
Uploaded: 2022-01-01
Description: Flat IP65 spotlight in black with 3 x 8 W 4in1 QCL RGBW LED, QuickDMX transceiver

Flat IP65 spotlight in black with 3 x 8 W 4in1 QCL RGBW LED, QuickDMX transceiver-MainBild

Flat IP65 spotlight in black with 3 x 8 W 4in1 QCL RGBW LED, QuickDMX transceiver-Bild-1

EUROLITE AKKU IP Flat Light 3 bk

Stock for approx. 12 wk(s)

259,00 €

Find a dealer

Stock for approx. 12 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 41700020

15°

Flat IP65 spotlight in black with 3 x 8 W 4in1 QCL RGBW LED, QuickDMX transceiver

Integrated QuickDMX transceiver for wireless DMX control
Cordless, flexible and versatile
Battery operation up to 16h depending on program used
Integrated automatic charging of the battery and status indicator
3 LEDs 8 W SMD 9080 4in1 QCL RGBW (homogenous color mix)
Dimmer electronic; Dimmer speed (step response) adjustable; color blend stepless; color change adjustable; colors preset
Strobe effect
The device is cooled by passive convection cooling
Control via master/slave function; IR remote control; QuickDMX; stand-alone; sound to light via microphone
Fixtures available for Light´J; Light Captain; EASY SHOW 1; EASY SHOW 2; EASY SHOW 3; Colorchief
Flicker-free
With a beam angle of 15°
With mounting bracket
LCD display
Suitable for outdoor use IP65
For application areas such as: Decoration; wedding/gala/events; mobile djs / entertainer; party room; restaurants, bars and hotels
Silent operation
Application possibility: Standing
