ML spot with 100 W COB LED and RGB color mixing
EUROLITE LED ML-56 COB RGB 100W Floor sil

ML spot with 100 W COB LED and RGB color mixing-MainBild

40°

ML spot with 100 W COB LED and RGB color mixing

EUROLITE LED ML-56 COB RGB 100W Floor sil

The article is no longer in our assortment.

No. 41607321

Print product

Product badge

Here you find the manual and downloads for
EUROLITE LED ML-56 COB RGB 100W Floor sil

ML spot with 100 W COB LED and RGB color mixing

The Eurolite LED ML-56 spotlight is equipped with a 100 Watts Chip-on-Board (COB) LED in RGB colors, which ensure homogeneous color mixing. It is suitable for use in theatres, on large stages as a front spotlight and for mobile use. Because of the additional stand bracket, the ML-56 can also be used as a floor spot.

The effect spotlight comes with a variety of functions: Automatic color change, internal and user-defined programs, dimmer and strobe effect with variably adjustable speed. The flicker-free projection even makes it possible to use the spotlight for video recording.

You can control the Eurolite LED ML-56 COB via DMX with master/slave function or in standalone mode. In addition, the built-in microphone allows you to operate the spotlight via music control.
Comfortable addressing and setting is possible via the Control Board with four operating keys and LED display.

Features

ML spot with 100 W COB LED and RGB color mixing

Equipped with one COB 100 W LED in RGB colors
Stepless color blend, color change, preset colors, dimmer and strobe effect
Adjustable white balance
Dimmer speed (step response) adjustable
Stand-alone, master/slave and DMX mode
Color presets can be called up via DMX controller
Strobe effect with adjustable speed
40° beam angle
Control panel with LED display for easy configuration
Additional bracket for floor use
2 swivel mounting brackets
With color filter frame
Optional barndoors available
Ideal for theatres, large stages as pre-stage spot and mobile use
Various versions available
1 powerful LED 100 W COB (chip-on-board) 3in1 TCL RGB (homogenous color mix)
Strobe effect
The device is cooled by cooling fan
Control via DMX; sound to light via microphone
Preprogrammed in EASY SHOW 1; Light´J; LED PC-Control 512; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE; Light Captain
Flicker-free
With a beam angle of 40°

Package contents

1 x filter frame

Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	90 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Fixed power supply cord with safety plug
Cable length:	Approx. 1,2 m
Lamp type:	LED lamp
LED type:	1 x 100 W COB (chip-on-board) 3in1 TCL RGB (homogenous color mix)
Flash rate:	0 - 17 Hz
DMX channels:	3; 3 (HSV hue/saturation/value); 5; 6; 9
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Cooling:	Cooling fan
Control:	DMX; sound to light via microphone
Preprogrammed in:	EASY SHOW 1; Light´J; LED PC-Control 512; EASY SHOW 1; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE; Light Captain
Projection:	Flicker-free
Beam angle:	40°
Beam angle (1/2 peak):	40°
Beam angle (1/10 peak):	82°
Housing color:	Silver
Dimensions:	Width: 31 cm Depth: 26 cm Height: 30 cm
Weight:	3,41 kg
Noise classification:	Class 3 (clearly perceptible sounds)
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting

Packaging units

PU	EAN	Weight	Dimensions
1	4026397588279	4,00 kg	29,5cm x 29,5cm x 39cm
4	4026397588286	17,60 kg	61cm x 61cm x 41cm

Accessories

Loading accessories. Please wait...

Support

Spare parts

LED COB 100W RGB ML-56 COB (JX-SPEC-WW-0100)

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support
