Technical specifications

Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	65 W
Power connection:	Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:	1 x P-Con (grey), mounting version
Lamp type:	LED lamp
LED type:	1 x 80 W COB (chip-on-board) 3in1 RGB (homogenous color mix)
DMX channels:	3; 5; 6; 7; 8
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Cooling:	Passive convection cooling
Control:	DMX; sound to light via microphone
Fixtures available for:	LED PC-Control 512; Light´J; EASY SHOW 1; LED EASY OPERATOR 4x4; LED EASY OPERATOR 4x6; LED EASY OPERATOR DELUXE; Light Captain; EASY SHOW 2; EASY SHOW 3; Colorchief
Projection:	Flicker-free
Beam angle:	16° spot
Beam angle (1/2 peak):	Spot 16° Wash effect 36°
Beam angle (1/10 peak):	Spot 28° Wash effect 78°
Housing color:	Black
Attachment system:	Double bracket Double bracket
Display type:	4 digit 7-segment LED display
Dimensions:	Width: 17.5 cm Depth: 25.7 cm Height: 16.9 cm
Weight:	2.04 kg
Noise classification:	Class 0 (no noise at all)

Packaging units

PU	EAN	Weight	Dimensions
1	4026397572599	2,31 kg	30cm x 18,5cm x 18cm
8	4026397574340	19,35 kg	64cm x 39cm x 39cm

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

Support

Name	Version	Language
41602595-Support-105580-1.0000-41602595-LED-PC-Control-fixtures-de.zip (6 KB)	1.0000	de
41602595-Support-136421-Fixture-fuer-Colorchief-V2x-de.zip (215 B)	0.0000	de

Video file

Name	Version	Language
41602595-Video-100575-de_en_es_fr.flv (26 MB)	0.0000	de_en_es_fr

All images

Name	Version	Language
41602595-Images-.zip

Video link

EUROLITE LED PML-80 COB RGB 80W Spot/Wash

The article is no longer in our assortment.

No. 41602595

16° spot

36° wash effect

Spotlight with 80 W COB LED (RGB), beam angle 16°/36° (lens)

Interchangeable front lens for 16° or 36° beam angle
In color change operation suitable for continuous use
Compact design
1 LED 80 W COB (chip-on-board) 3in1 RGB (homogenous color mix)
Color blend stepless; color change adjustable; colors preset; Dimmer electronic; Dimmer speed (step response) adjustable
Strobe effect
Can be operated in 3; 5; 6; 7; 8 CH mode
The device is cooled by passive convection cooling
Control via DMX; sound to light via microphone
Flicker-free
With a beam angle of 16° spot
With double bracket
4 digit 7-segment LED display
Mains input and output for power linking up to 8 units
For application areas such as: Clubs/dancing school; decoration; restaurants, bars and hotels; theater; advertisement/Shop window
Silent operation
Application possibility: Standing; suspended; on stand
