Practical 32 A distributor in 483 mm housing (19")
EUROLITE SBM-32 Power Distributor

EUROLITE

Practical 32 A distributor in 483 mm housing (19")

EUROLITE SBM-32 Power Distributor

Stock for approx. 4 wk(s)
445,00
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 30248400

svg
3 U
svg
Features

Practical 32 A distributor in 483 mm housing (19")

  • Specially designed for larger distribution needs
  • 3 U necessary for installation
  • 32 A three phase current input via 5 x 6 mm² power cable and plug
  • The entire distributor is secured via 30 mA Residual Current Device (RCD)
  • Voltage and current display of every phase
  • 32 A three phase current output on the rearpanel
  • 6 safety sockets on the housing back (2 per phase)
  • Each safety socket feature fuse protection via 16 A automatic circuit breakers
  • With M6 earthing screw in order to ground a rigg if necessary
  • Power output: 1 x CEE 32A 5-pol (f) recessed mounting Bypass
  • Power output: 6 x Protective contact (F) hinged lid mounting version fused
  • Housing design: (19") 48.3 cm rack installation 3 U
Technical specifications
Power connection:Fixed CEE 32A 5-pin (M)
Power output:1 x CEE 32A 5-pol (f) recessed mounting Bypass
6 x Protective contact (F) hinged lid mounting version fused
Housing design:(19") 48.3 cm rack installation 3 U
Width:48,3 cm
Height:13,35 cm
Depth:23 cm
Weight:5,80 kg
Power supply:380-400 V AC, 50 Hz
Max. power output:22080 W
Max. output/phase:7360 W
Max. current/phase:32 A
Fuses:6 x 16A 1 Ph, FI/RCD 40A/0.03A
Height:3 U
Packaging units
PU EAN Weight Dimensions
1 4026397529630 6,20 kg 50cm x 31cm x 21,5cm
2 4026397529647 13,35 kg 53cm x 33cm x 45,5cm
Support
Spare parts
Loading spareparts. Please wait...
Downloads
User manual
Name Version Language
30248400-Manual-85220-3.000-de_en.pdf (197 KB) 3.000 de_en
All images
Name Version Language
30248400-Images.zip
Publications
main catalog 2019 St. E #28
On page: 293
Size: 284 MB
