EUROLITE Set 2x LED BAR-6 QCL RGBA + Soft Bag

EUROLITE



EUROLITE Set 2x LED BAR-6 QCL RGBA + Soft Bag

Stock for approx. 12 wk(s)
149,00
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 20000414

svg
svg
17°
svg
svg
svg
svg
svg
svg
Features

51930397 EUROLITE LED BAR-6 QCL RGBA Bar

Spotlight bar (60 cm) with 6 x 4 watt 4in1 LED (RGBA)

  • Operable in stand-alone mode or via DMX
  • DMX512 control possible via any commercial DMX controller (occupies max. 9 channels)
  • 2, 4, 5, 6, or 9 DMX channels selectable
  • Sound-control via built-in microphone
  • Microphone sensitivity adjustable via Control Board
  • Comfortable addressing and setting via control board with LED display and four operating buttons
  • Functions: Static colors, RGBA color blend, color temperature settings, internal programs, dimmer and strobe settings, Master/Slave
  • Equipped with 6 x 4 W QCL LED in the colors red, green, blue and amber
  • Hanging as well as standing installation possible
  • Locking possibility at the mounting bracket
  • Feed-through output allows to power up to 8 devices
  • Switch-mode power supply for operation between 100 and 240 volts
  • Ready for connection via enclosed IEC power cord with safety-plug
  • Case color: Black
  • Effect: Strobe effect
  • Projection: flicker-free
  • Power connection: Mains input IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
  • Power output: 1 x IEC connector (F) mounting version
  • Control: Stand-alone; DMX
  • LED: 6 x high-power 4 W 4in1 QCL RGBA (homogenous color mix)

30130580 EUROLITE SB-205 Soft Bag

Universal softbag, 575 x 170 x 120 mm

  • Big universal compartment with divider
  • Ideal for e.g. LED bars with 50 cm length and accessories
  • Interior upholstery helps securing and safeguarding the fixtures during transportation
  • Made of easy-care nylon
  • Two handles with velcro fastener
Technical specifications
51930397 EUROLITE LED BAR-6 QCL RGBA Bar
DMX channels:2/4/5/6/9
DMX connection:3-pin XLR
Sound-control:via built-in microphone
Flashrate:20 Hz
Type of LED:4 W RGBA (4in1)
LED number:6
Beam angle:17°
Dimensions (L x W x H):585 x 65 x 100 mm
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
IP classification:IP20
Beam angle:17°
Cooling fan:No, cooling by convection
Weight:1,81 kg
Power consumption:15 W
Height:10 cm
Depth:6,5 cm
Length:59 cm
Power connection:Mains input IEC connector (M) mounting version Power supply cord with safety plug (M)
Power output:IEC connector (F) mounting version
DMX channels:2; 4; 5; 6; 9
LED:6 x high-power 4 W 4in1 QCL RGBA (homogenous color mix)
Power supply:110-240 V AC, 50/60 Hz
30130580 EUROLITE SB-205 Soft Bag
Outside dimensions (L x W x H):575 x 170 x 120 mm
Color:Black
Weight:0,3 kg
Maximum load:25 kg
Width:57,5 cm
Depth:17 cm
Height:12 cm
Material:Textile
Packaging units
PU EAN Weight Dimensions
1 4026397621198 8,20 kg 61cm x 31cm x 42cm
