EUROLITE Set 4x AKKU TL-3 TCL Trusslight + Case

16°

7 mm

EUROLITE Set 4x AKKU TL-3 TCL Trusslight + Case

The article is no longer in our assortment.

Item no. 20000278

Print product

Product badge

41700500 EUROLITE AKKU TL-3 TCL Trusslight

The AKKU TL-3 TCL is a spotlight equipped with 3 bright 3-watt RGB LEDs (3in1) designed for lighting within trussing. It is wireless and battery-run (battery life 6.5 hours) and its small size makes it a great fit for many 3- and 4-point trussing systems.

You can choose from a variety of different functions such as static colors, continuous RGB color mixture, internal programs, dimmer effects as well as strobe effects with adjustable speed.

The device can either be controlled via DMX or the supplied wireless remote control (Eurolite IR-7).
All of these features make the AKKU TL-3 TCL the perfect choice for booth construction, stages and any kind of truss.

Features

Set consisting of:
4x 41700500: EUROLITE AKKU TL-3 TCL Trusslight
1x 31005111: ROADINGER Flightcase 4x AKKU TL-3 TCL Trusslight

41700500 EUROLITE AKKU TL-3 TCL Trusslight

Spotlight with 3 x 3 W 3in1 LED (RGB) for lighting within trussing

Compact and bright, making it perfect for truss installation
Cordless, flexible and versatile
Equipped with 3 x 3 W TCL LED in red, green and blue
Operation via mains connection or built-in rechargeable lithium-ion battery with up to 6.5 hours operating time
Integrated automatic charging of the battery with indicator
Controllable via EUROLITE IR-7 remote control; included in the delivery
DMX-controlled operation or stand-alone operation with Master/Slave function
3, 5 or 8 DMX channels selectable
Functions: static colors, stepless RGB color mixture, internal programs, dimmer, strobe effect with variable speed, sound-control, Master/Slave operation
Dimmer speed (step response) adjustable
Adjustable microphone sensitivity
Addressing via control panel with 4-digit LED display
Ideal for booth construction, stages and any kind of truss
Ideal for ALUTRUSS 3-POINT SYSTEM DECOLOCK DQ3
Hanging as well as standing installation possible
Switch-mode power supply for operation between 100 and 240 volts
Ready for connection via included power cable with safety power plug
Feed-through output allows to power up to 8 devices
Control: IR remote control included; DMX; Sound to light via Microphone; Stand-alone
Projection: flicker-free

Remote control

Battery: 1 x Button cell 3.0 V CR2025 lithium manganese built-in

31005111 ROADINGER Flightcase 4x AKKU TL-3 TCL Trusslight

PRO flightcase for 4 AKKU TL-3 TCL Trusslights

Interior seperated in four compartments, for four AKKU TL-3 TCL Trusslight
Additional accessory compartment
High-quality workmanship with wood, dark brown laminated
Aluminum profile frames (25 mm) with rounded edges
Interior upholstered with foam
Three-leg, small-sized steel ball corners
2 tip-over locks
High-quality butterfly lock
Case handle
Made in Europe

Technical specifications

41700500 EUROLITE AKKU TL-3 TCL Trusslight
Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	19,00 W
IP classification:	IP20
Power connection:	Battery/battery pack
	Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided)
Power output:	1 x IEC connector (F) mounting version
LED:	3 x high-power 3 W 3in1 TCL RGB (homogenous color mix)
Beam angle:	16°
Flash rate:	0 - 30 Hz
DMX channels:	3; 5; 8
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Control:	IR remote control included
	DMX
	Sound to light via Microphone
	Stand-alone
Housing color:	Black
Width:	12,1 cm
Height:	13,6 cm
Depth:	10,8 cm
Weight:	1,35 kg
Device
Battery pack type:	1 x Lithium ion 11,1 V, 4400 mAh, 48,84 Wh
Accumulator:	battery operation up to 6,5h depending on program used recharging time 4,5h
Remote control
Battery:	1 x Button cell 3.0 V CR2025 lithium manganese built-in
Legal specifications
Ecodesign regulation:	Yes
Special product:	Not designed for household room illumination
Purpose:	Show effect lighting
31005111 ROADINGER Flightcase 4x AKKU TL-3 TCL Trusslight
Maximum load:	25 kg
Color:	Dark brown laminated
Material:	Birch multiplex 7 mm
Strength:	7 mm
Width:	47,5 cm
Height:	21,5 cm
Depth:	24,5 cm
Weight:	4,50 kg
