Technical specifications

Weight:	7.93 kg
EUROLITE LED SLS-7 QCL 7x10W Floor
Power supply:	100-240 V AC, 50/60 Hz
Power consumption:	63 W
Protection class:	Protection class II
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Cable length:	1.5 m
Power output:	1 x IEC connector (F) mounting version
Fuse:	5 x 20 mm, F 1 A fuse replaceable
Lamp type:	LED lamp
LED type:	7 x 10 W high-power 4in1 RGBW (homogenous color mix)
DMX channels:	5; 6; 8
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Cooling:	Cooling fan
Control:	Stand-alone; DMX; sound to light via microphone; master/slave function
Fixtures available for:	LED PC-Control 512; Light Captain
Beam angle (1/2 peak):	21°
Beam angle (1/10 peak):	41°
Housing color:	Black
Dimensions:	Width: 21 cm Depth: 11 cm Height: 22 cm
Weight:	1.47 kg
Photobiological safety:	Risk Group 0
Legal specifications
Special product:	Not designed for household room illumination
Intended use:	Show effect lighting
EUROLITE SB-18 Soft Bag
Maximum load:	25 kg
Carrying strap:	2 pc/pcs
Material:	Textile
Color:	Black
Dimensions:	Width: 47 cm Depth: 24 cm Height: 30 cm
Weight:	0.60 kg

Spare parts

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
20000223-Images-.zip

Video link

EUROLITE Set 5x LED SLS-7 QCL + Case

The article is no longer in our assortment.

No. 20000223

21°

Set consisting of:

5 x EUROLITE LED SLS-7 QCL 7x10W Floor

1 x EUROLITE SB-18 Soft Bag

5x flat spotlight with 7 x 10 W 4in1 LED including practical black soft bag

EUROLITE LED SLS-7 QCL 7x10W Floor

Slim design for space-saving applications
7 high-power 10 W RGBW LEDs (4in1)
Built-in auto and music show programs
Stepless color blend, color change, color fade, dimmer and strobe effect
Control panel with LED display for easy configuration
Flat, lightweight ABS housing with rubber feet
Sits flat on the floor or inside a truss
DMX and power terminals intelligently designed for easy wiring
Swivel mounting bracket
Mains input and output for power linking up to 8 units
7 LEDs 10 W high-power 4in1 RGBW (homogenous color mix)
Strobe effect
The device is cooled by cooling fan
Control via stand-alone; DMX; sound to light via microphone; master/slave function
With a beam angle of 21°

EUROLITE SB-18 Soft Bag
