Steinigke Showtechnic GmbH - Your wholesale company for event technology. We only sell to commercial customers. All prices without tax.



7 mm


Item no. 20000183

51930414 EUROLITE LED PIX-16 QCL Bar

Compact LED color changing bar with 16 x 8 W QCL LED

  • Equipped with sixteen QCL LEDs in the colors red, green, blue and white
  • Particularly bright illuminating power of the LEDs
  • 4, 6, 7, 11, 19, 64, 67 DMX channels selectable for various applications
  • Each LED can be controlled individually
  • Programmable color change speed, strobe effect and dimmer
  • Strobe effect with 1-18 flashes per second
  • RGBW color mixing
  • Static colors
  • Internal programs
  • DMX-controlled operation or stand-alone operation with Master/Slave function
  • Manual, sound or DMX-controlled operation
  • For large stage backgrounds in public places, main halls and lounges
  • Hanging as well as standing installation possible
  • Locking possibility at the mounting bracket
  • Sound-controlled via built-in microphone
  • Addressing via control panel with LCD screen
  • Ready for connection with power-cable and plug
  • Feed-through output allows to power another device
  • After every 8 devices the fixtures must have a renewed connection with the power mains
  • Switch-mode power supply, automatic power supply adaption between 100 and 250 volts
  • DMX512 control possible via any commercial DMX controller
  • Can be operated in 6; 4 CH mode
  • Is in Light J Software already preprogrammed

31005010 ROADINGER Flightcase 4x LED PIX-16 TCL/QCL

PRO flightcase for 4 x LED PIX-16 TCL/QCL

  • Compartments for 4 x LED PIX-16
  • High-quality workmanship with birch multiplex
  • Interior separated into 4 compartments
  • Aluminum profile frames with rounded edges
  • Three-leg, small steel ball corners
  • 2 butterfly locks
  • 3 hinged, zinc-plated case handles
  • 2 corner castors for trolley
  • Transport aid: Trolley
Technical specifications
Weight:42.90 kg
51930414 EUROLITE LED PIX-16 QCL Bar
Power supply:100-240 V AC, 50/60 Hz
Power consumption:200 W
DMX channels:6; 4
Control:Light J Software
Dimension:Length: 100 cm
Depth: 9 cm
Height: 17 cm
Dimension:Length: 1000 mm
Weight:7.30 kg
Beam angle:25°
LED number:16
LED type:8-W-QCL
DMX channels:4/6/7/11/19/64/67
DMX connection:3-pin XLR
Sound-control:via built-in microphone
Dimensions (L x W x H):1000 x 170 x 90 mm
Legal specifications
Ecodesign regulation:Yes
Special product:Not designed for household room illumination
Purpose:Show effect lighting
31005010 ROADINGER Flightcase 4x LED PIX-16 TCL/QCL
Maximum load:50 kg
Material:Birch multiplex, 7 mm
Color:Black, laminated
Dimension:Width: 113 cm
Depth: 51.5 cm
Height: 27 cm
Weight:13.70 kg
Strength:7 mm
Outer dimensions (L x W x H):1130 x 515 x 270 mm
Inside dimensions (L x W x H):1060 x 470 x 225 mm
