Wireless microphone system with UHF PLL technology
OMNITRONIC UHF-101 Wireless Mic System 864.8MHz

svg
Microphone 5.4 cm
svg
svg
Receiver 1 U
OMNITRONIC

Wireless microphone system with UHF PLL technology

OMNITRONIC UHF-101 Wireless Mic System 864.8MHz

Item no. 13063261

Features

Wireless microphone system with UHF PLL technology

  • Receiver unit and hand-held microphone with UHF PLL technology
  • Available in the license-free frequency ranges 823-832 MHz and 863-865 MHz
  • Parallel operation of up to 8 transmission channels is possible without any interference
  • Volume control
  • XLR and 6.3 mm output
  • Jack cable included
  • LEDs for power, carrier and audio signal
  • Microphone with color indication
  • Matching pocket transmitter can be ordered separately
  • 483 mm rack installation possible with optional mounting brackets
  • License-free and approved in large parts of the EU (please check Duplex Gap on a country-by-country basis)
  • Use a operating range with line of sight up to 60m with line of sight

Receiver

  • Desktop console housing; (19") 48.3 cm rack installation (optional) 1 U

Microphone

  • Polar pattern: Cardioid
Technical specifications
Type:Wireless set
Number of channels:1
Frequency range:40 - 18000 Hz
S/N ratio:>105 dB
Carrier frequency:864.800 MHz
Frequency selection:Fixed frequencys
Range:60 m with line of sight
Switch:On/off switch
Weight:1.10 kg
Receiver
Power supply:100-240 V AC, 50/60 Hz
12 V DC 350 mA
Power consumption:5 W
Power connection:Mains input Coaxial power connector (M) Power supply cord with AC adapter (provided)
Material:Metal
Housing design:Desktop console housing
(19") 48.3 cm rack installation (optional) 1 U
Width:20.5 cm
Height:4.6 cm
Depth:22.5 cm
Microphone
Power supply:3 V DC
Power connection:Battery/battery pack
Capsule type:Dynamic
Polar pattern:Cardioid
Battery:2 x Mignon (AA) (not included)
Material:Plastic
Length:26 cm
Diameter:5.4 cm
Weight:0.23 kg
System:Non-diversity
RF power output:5 mW
Modulation method:F3F
Selectivity:>85 dB
T.H.D.:<0.5 % at 1 kHz
Audio outputs:400 mV, 2.2 kohms (XLR, bal.)
200 mV, 2.2 kohms (6.3 mm jack, unbal.)
Packaging units
PU EAN Weight Dimensions
1 4026397603668 1,40 kg 34cm x 34cm x 7cm
10 4026397613636 15,05 kg 72cm x 36cm x 42cm
