System with DSP for microphone modeling and PC software, 823-832 + 863-865 MHz
RELACART UR-260D 2-channel UHF System 823-832 + 863-865 MHz

svg
svg
svg
5,4 cm
svg
svg
svg
svg
1 U
svg
svg
RELACART

System with DSP for microphone modeling and PC software, 823-832 + 863-865 MHz

RELACART UR-260D 2-channel UHF System 823-832 + 863-865 MHz

delivery date unknown
519,00
add to cart
Find a dealer
List price excl. 19% VAT
Prices in retail stores may vary.
Item no. 13055212
Set consisting of:
mpn13055210
1 x RELACART UR-260D 2-channel UHF Receiver 823-832 + 863-865 MHz
mpn13055206
2 x RELACART UH-222D Microphone 823-832 + 863-865 MHz
The UR-260D is a dual-channel true diversity UHF system with a host of innovative features. In addition to automatic frequency scanning for interference-free transmission, one also finds an intelligent feedback suppression system. With MagicEQ, various sound characteristics of world-known microphone capsules can be emulated or created yourself. The presets can be changed from a computer via software - even during live operation.
Features

System with DSP for microphone modeling and PC software, 823-832 + 863-865 MHz

Package contents

  • 1 x receiver, 2 x antenna, 1 x external mains adapter, 2 x microphone, 1 x jack cable, 1 x mounting bracket, 1 x bag, 1 x user manual, 1 x declaration of conformity

RELACART UR-260D 2-channel UHF Receiver 823-832 + 863-865 MHz

Diversity wireless receiver with DSP for microphone modeling and PC software

  • 2-channel multifrequency wireless receiver with 24-bit processor for high-end audio quality
  • Integrated MagicEQ enables amazing microphone modeling of hand-held microphones
  • Choose from 7 presets based on popular microphone models (e835, beta58, e935, D5, SM57, N/D767a, SM58) and 3 user-definable presets
  • Integrated Feedback Killer effectively eliminates feedback, providing maximum gain and increased clarity on every microphone
  • DSP programming and management via Ethernet port and intuitively operated PC software
  • High-quality antenna diversity reception
  • 10 groups with 90 fixed frequencies within 11 MHz switching bandwidth
  • Pilot frequency squelch technology delete wireless RF interference
  • Automatic frequency scan (AFS) finds interference-free channels
  • Easy and error-free synchronization between receiver and transmitter via infrared signal
  • Multiple units can be linked with network cables
  • Lock function for prevents undesired changes to settings
  • 2 detachable BNC antennas allow for use with the R-14D antenna divider
  • Rugged metal housing
  • Digital signal processor 96kHz, 24 bit
  • Multicolor LCD display
  • UHF 863 - 865 MHz License-free and approved in Europe
  • UHF 823 - 832 MHz License-free and approved in large parts of Europe
  • Operating range up to 80m
  • The device can be connected via RJ-45 (F) mounting version to the PC in connection with RELACART Magic EQ software
  • Desktop console housing
  • (19") 48.3 cm rack installation possible 1 U
  • Up to 9 transmitters can be operated in parallel without interference

Package contents

  • 1 x receiver, 2 x antenna, 1 x external mains adapter, 1 x jack cable, 2 x mounting bracket, 6 x screw, 1 x user manual, 1 x declaration of conformity

RELACART UH-222D Microphone 823-832 + 863-865 MHz

Hand-held microphone with PLL multifrequency transmitter

  • Dynamic hand-held microphone with UHF pilot tone technology (PLL)
  • Ergonomic aluminum alloy housing, applicable for touring
  • 10 groups with 90 fixed frequencies within 11 MHz switching bandwidth
  • Easy and error-free synchronization between receiver and transmitter via infrared signal
  • RF output power Hi/Low adjustable
  • Gain level Hi/Mid/Low adjustable
  • Capsule M-022
  • Directly compatible with Shure's SM58 capsule
  • Polar pattern: Super cardoid
  • Operating range up to 80m
  • UHF 863 - 865 MHz License-free and approved in Europe
  • UHF 823 - 832 MHz License-free and approved in large parts of Europe
  • OLED display
  • Charge status indicator

Package contents

  • 1 x microphone, 1 x user manual, 1 x declaration of conformity
Technical specifications
Type:Wireless set
Weight:2,97 kg
RELACART UR-260D 2-channel UHF Receiver 823-832 + 863-865 MHz
Type:Receiver
Power supply:100-240 V AC, 50/60 Hz
12 V DC 1 A
Power consumption:Max. 9 W
Power connection:Mains input via coaxial power connector (M) mounting version power supply cord with AC adapter (provided)
Number of channels:2
Frequency range:45 - 18000 Hz
S/N ratio:>100 dB
THD:<0,5 % at 1 kHz
Network connection:Protocol: Ethernet TCP/IP via 1x RJ-45 (F) mounting version
DSP:Digital signal processor 96kHz, 24 bit
Range:Range up to 80m
Frequency band:UHF 863 - 865 MHz; UHF 823 - 832 MHz
Diversity:Antenna diversity
Switching bandwidth:11 MHz
Frequency stability:± 0,0005 %
Parallel mode:Max. 9 transmitter
Modulation:FM
Frequency selection:90 switchable frequencies
In 10 groups with up to 10 preset frequencies each
Display type:Multicolor LCD display
Control elements:Power switch, groundlift selector, menu, navigation keys
Connections:Antenna via 2 x BNC (F) 8 V
Output: microphone via 2 x 3-pin XLR (M) mounting version
Output: line via 1 x 6.3 mm plug (unbal.)
Material:Metal
Color:Black
PC connect:RELACART Magic EQ software via RJ-45 (F) mounting version
Housing design:Desktop console housing
(19") 48.3 cm rack installation possible 1 U
Dimensions:Width: 41 cm
Depth: 26 cm
Height: 4,3 cm
Weight:2,40 kg
RELACART UH-222D Microphone 823-832 + 863-865 MHz
Type:Hand-held transmitter
Power supply:3 V DC
Capsule type:Dynamic
Polar pattern:Super cardoid
Battery:2 x Mignon (AA) (not included)
Frequency range:120 - 16000 Hz
Sensitivity:-53 dB
Max. SPL:145 dB
Range:Range up to 80m
Frequency band:UHF 863 - 865 MHz; UHF 823 - 832 MHz
Switching bandwidth:11 MHz
RF power output:10 mW
Modulation:FM
Frequency selection:90 switchable frequencies
In 10 groups with up to 10 preset frequencies each
Display type:OLED display
Display:Charge status indicator , frequency , channel
Control elements:Gain-switch (high-mid-low), transmitter power switch (high-low)
Switch:On/off/mute switch
Material:Aluminum
Dimensions:Length: 26 cm
Diameter: Ø 5,4 cm
Weight:280 g
Packaging units
PUEANWeightDimensions
140263975257863,80 kg59cm x 43cm x 9cm
24026397610635
4402639753729116,30 kg45cm x 37cm x 63cm
