Precise measuring microphone with flat frequency response
OMNITRONIC MIC MM-1C Condenser Measurement Mic

OMNITRONIC

Precise measuring microphone with flat frequency response

OMNITRONIC MIC MM-1C Condenser Measurement Mic

Stock for approx. 12 wk(s)
34,90
Save money: This article is available in a bundle.
add to cart
Find a dealer
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 13030919

svg
13 cm
Save money: This article is available in a bundle.
Sets are loaded. Please wait...
Features

Precise measuring microphone with flat frequency response

  • Electret measuring microphone for measuring systems and audio recordings
  • Designed for measuring PA systems, speakers and room acoustics
  • Perfect complement to any real-time analyzer
  • Flat frequency response for high precision
  • True omnidirectional pattern
  • Sturdy all-metal construction and narrow design
  • Incl. microphone clip, thread adapter (9 mm/3/8") and windscreen
  • Polar pattern: Omnidirectional
  • Mute function: No
Technical specifications
Polar pattern:Omnidirectional
Frequency range:20 - 20000 Hz
Phantom power:9 V - 52 V DC
Microphone-Type:Condenser
Type:Microphone for measurements
Length:19,2 cm
Diameter:13 cm
Weight:0,10 kg
Type:Condenser (back electret)
Operating principle:Pressure gradient, FET preamp
Polar pattern:omnidirectional
Sensitivity: -37 dB (±3 dB)
Nominal impedance: 200 ohms
Load impedance: 1000 ohms
Maximum SPL:134 dB (THD <1% at 1 kHz)
S/N ratio: 76 dB
Phantom power:9-52 V DC
Current consumption: 3 mA
Connection: 3-pin XLR
Packaging units
PU EAN Weight Dimensions
1 4026397556810 0,17 kg 22cm x 11cm x 4,5cm
20 4026397561043 4,00 kg 47cm x 24cm x 25cm
