350 W AES, 8 ohms, 97 dB, 55-3000 Hz
LAVOCE WAF122.50 12" Woofer Ferrite Magnet Aluminium Basket Driver

Name: LAVOCE WAF122.50 12" Woofer Ferrite Magnet Aluminium Basket Driver
Brand: LAVOCE

Stock for approx. 12 wk(s)

114,00 €

Find a dealer

Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Features

350 W AES, 8 ohms, 97 dB, 55-3000 Hz

Experienced Italian R&D team with outstanding technical know-how
Innovation-driven culture
Superb and elegant Italian mechanical & aesthetical design
Strictest standards and tools in testing and validation
Modern and efficient production system with a carefully balanced level of automation
Total Quality Management system
Efficient logistics
ISO 9001 certification

Technical specifications

Type:	30 cm woofer (12")
Rated power:	350 W AES
Program power:	700 W
Impedance:	8 ohms
Sensitivity:	97 dB
Voice coil diameter:	6.5 cm (2.5")
Chassis material:	Aluminum
Magnet material:	Ferrite
Frequency range:	55 - 3000 Hz
Impedance:	8 Ohm
Diameter:	(12") ca. 30 cm Basket diameter; (2,5") ca. 6 cm Moving coil
Weight:	6,3 kg

Packaging units

PU	EAN	Weight	Dimensions
1	4026397635157	7,75 kg	35,6cm x 35,6cm x 19,2cm
1	4026397632620	7,60 kg	46cm x 35,5cm x 28cm
2	4026397624625	14,55 kg	35,5cm x 35,5cm x 36,5cm
