Technical specifications

Power:	Peak: 1800W Program: 900W Rated: 450W RMS
Frequency range:	95 - 22000 Hz
Sensitivity:	98 dB (1W/1m)
Max. SPL:	136 dB
Dispersion angle:	100° x 12° (array dependent)
Impedance:	16 ohms
Flying points:	With integrate rigging system
Control elements:	Mode switch (1+1- / 2+2-)
Connections:	Input: 2 x 4-pol SpeakON mounting version (F)
Crossover frequency:	Passive 1100 Hz
Speaker:	1 x midrange speaker 10" with neodymium magnet Basket material: aluminum Voice coil midrange speaker 3" 1 x annular compression driver 1" with neodymium magnet Voice coil annular 1.75" Diaphragmmaterial: PEEK (H.T. polymer) with wave guide
Type of speaker:	Coaxial speaker
Type of construction:	Vented
Transport aid:	Wheelboard optional
Material:	Birch multiplex, CNC made with tongue and grove assembly
Color:	Black, rubberized Polyurea coating
Dimensions:	Width: 42 cm Depth: 39 cm Height: 28 cm
Weight:	16.75 kg

Spare parts

CELTO Diaphragma ACD44-12DK (IR10+/CMP12)

CELTO Coaxial speaker 10" LF+HF 10CXN400LA (IR10+ without IsoTop)

CELTO Push pin for IR10+

CELTO HF Driver ACDN44-12

CELTO locking screw for CMP10-YOKE U-Shape Bracket

component (Curve-Adaptor) IR10+ 2-way Coaxial Line Array Module

Downloads

Spezifications

Name	Version	Language
Spezifications as PDF
Product badge
Specifications as PDF neutral
Product badge neutral

All images

Name	Version	Language
11043730-Images-.zip

Publications

Move Magazine #1/2025 E

On page: 89

Size: 22 MB

CELTO IR10+ 2-way Coaxial Line Array Module

Game changer, all-in-one full-range coaxial line source-MainBild

Game changer, all-in-one full-range coaxial line source-Bild-1

CELTO IR10+ 2-way Coaxial Line Array Module

Stock for approx. 12 wk(s)

Priceon demand

Find a dealer

Stock for approx. 12 wk(s)

List price excl. 19% VAT
Prices in retail stores may vary.

No. 11043730

IsoRay10 coaxial passive line source speaker is suitable for near to far field main PA reinforcement in line array
topolgy with subwoofer for mobile and permanent installations.

Suitable in situations like:
-FoH
-Live Shows
-Multi-functional Rooms
-Auditoriums and theaters
-Sports Center
-House of Worship

Game changer, all-in-one full-range coaxial line source

10'' ultra compact line source
Real 450W RMS power capacity (8 hours pink noise)
Tiny A3 paper size format
Unmatched size/SPL ratio
16 ohm (passive) for high power density
Up to 24 speakers per array with 12 times safety
Wheelboard optional
Rubberized Polyurea coating
