Exclusive design, ultimate exterior finish
| Rated power: | 1200 W RMS |
| Program power: | 2400 W |
| Frequency range: | 26 - 110 Hz |
| Sensitivity: | 100 dB |
| Max. SPL: | 134 dB |
| Dispersion angle: | Omnidirectional |
| Crossover frequency: | active mode only |
| Recommended | |
| high-pass 30 Hz, 24db/oct | |
| low-pass 80-110 Hz when used with HX12 | |
| Impedance: | 8 Ohm |
| Color: | Orange, High-gloss, painted; any RAL color available on request |
| Attachment system: | M20 thread |
| Connections: | Input: 2 x Speakers via 4-pol SpeakON mounting version (F) |
| Speakers: | 1 x woofer (18") approx 45 cm with Neodymiummagnet |
| Voice coil lows (4") approx. 10 cm | |
| Material: | Finnish WISA birch plywood, 25 mm, CNC made with tongue and grove assembly |
| Width: | 58 cm |
| Height: | 70 cm |
| Depth: | 73 cm |
| Weight: | 55.00 kg |
| Low Frequency driver: | Custom made 18" CELTO driver |
| Neodymium magnet, 4" In / Out Voice coil, dual demodulating rings | |
| Connectors: | 2x NEUTRIK Speakon® NL4MP (1+/1- Link, 2+/2- Input & Link) |
| Finish: | 15-layer piano lacquer, |
