Pro PA speaker, 15" woofer, 6,5" mid, 1,4" horn, 1000 W RMS (Biamp)
PSSO K-315HD 3-Way Top 1000W

PSSO

Pro PA speaker, 15" woofer, 6,5" mid, 1,4" horn, 1000 W RMS (Biamp)

PSSO K-315HD 3-Way Top 1000W

Stock for approx. 12 wk(s)
1.499,00
add to cart
This is a bulky product.
Recommended retail price (RRP) excl. VAT
Prices in retail stores may vary.

Item no. 11041112

Features
  • Rugged full-range top speaker, qualified for suspension and touring applications
  • Biamp operation
  • Housing made of 15 mm/18 mm birch plywood
  • 38 cm neodymium bass speaker (15") and 16.5 cm midrange speaker (6.5") with diecast aluminum basket
  • 36 mm neodymium hybrid horn tweeter (1.4") with 72 mm voice coil (2.8")
  • Premium custom-made drivers by European manufacturer CELTO Acoustique
  • Bassreflex system
  • Parallel Neutrik Speakon connectors
  • Trapezoidal multi-functional housing with scratch-resistant lacquer surface
  • Impact-resistant steel grille with acoustic foam
  • Flange for stand installation
  • Applications: standing, on a subwoofer or speaker stand, suspended
Technical specifications
Rated power:700 W RMS LF
300 W RMS MHF
Components:38 cm woofer (15"), 16.5 cm driver (6.5"), 3.6 cm horn tweeter (1.4")
Connection: 2 x Speakon
Sensitivity:
LF98 dB
MHF:108 dB
Maximum SPL:137 dB
Impedance:
LF:8 ohms
MHF:8 ohms
Frequency range:45-20000 Hz
Crossover frequency:500 Hz and 2.5 kHz
Dispersion angle:70° x 40° above 600 Hz
Dimensions (H x W x D):800 x 445 x 443 mm
Weight:37 kg
Size of woofer:38 cm (15")
Number of bass-woofer:1 Stück
Packaging units
PU EAN Weight Dimensions
1 4026397483079 40,70 kg 56cm x 55cm x 91,5cm
