| Components: | 38 cm woofer (15"), 3.8 cm horn (1.5") |
| Connection: | 2 x Speakon |
| Sensitivity: | 99 dB |
| Maximum SPL: | 127 dB |
| Crossover frequency: | 1.5 kHz |
| Dispersion angle: | 80° x 50° |
| Dimensions (H x W x D): | 710 x 445 x 415 mm |
| Weight: | 29,45 kg |
| Rated power: | 600 W RMS |
| Size of woofer: | (15") ca. 38 cm |
| Number of bass-woofer: | 1 Pc/Pcs |
| Program power: | 1200 W |
| Frequency range: | 47 - 19000 Hz |
| Height: | 71 cm |
| Depth: | 41,5 cm |
| Width: | 44,5 cm |
| Impedance: | 8 Ohm |
| Material: |
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397545401 | 32,45 kg | 51cm x 49cm x 79cm |
| Name | Version | Language |
|---|---|---|
| 11041109-Manual-90650-1.30-de_en.pdf (4 MB) | 1.30 | de_en |
| Name | Version | Language |
|---|---|---|
| 11041109-Page-97794-25.00-de.pdf (376 KB) | 25.00 | de |
| 11041109-Page-97894-25.00-en.pdf (374 KB) | 25.00 | en |
| 11041109-Page-115028-27.00-de.pdf (350 KB) | 27.00 | de |
| 11041109-Page-115465-27.00-en.pdf (339 KB) | 27.00 | en |
| Name | Version | Language |
|---|---|---|
| 11041109-Images.zip |
