| Rated power: | 400 W RMS |
| Components: | 38 cm woofer (15"), 2.5 cm horn (1") |
| Connection: | 2 x Speakon |
| Sensitivity: | 98 dB |
| Maximum SPL: | 130 dB |
| Crossover frequency: | 1.7 kHz |
| Dispersion angle: | 80° x 50° |
| Dimensions (H x W x D): | 710 x 445 x 415 mm |
| Weight: | 26 kg |
| Size of woofer: | 38 cm (15") |
| Number of bass-woofer: | 1 Stück |
| Frequency range: | 47 - 19000 Hz |
| Height: | 71 cm |
| Depths: | 41,5 cm |
| Width: | 44,5 cm |
| Loudspeaker control: | 8 Ohm |
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397481846 | 28,60 kg | 48,5cm x 51cm x 79,5cm |
| Name | Version | Language |
|---|---|---|
| 11041108-Manual-73848-1.00-de_en.pdf (977 KB) | 1.00 | de_en |
| 11041108-Manual-77804-1.10-de_en.pdf (2 MB) | 1.10 | de_en |
| 11041108-Manual-83314-1.20-en_de.pdf (4 MB) | 1.20 | en_de |
| Name | Version | Language |
|---|---|---|
| 11041108-Page-97794-25.00-de.pdf (376 KB) | 25.00 | de |
| 11041108-Page-97894-25.00-en.pdf (374 KB) | 25.00 | en |
| 11041108-Page-115028-27.00-de.pdf (350 KB) | 27.00 | de |
| 11041108-Page-115465-27.00-en.pdf (339 KB) | 27.00 | en |
| Name | Version | Language |
|---|---|---|
| 11041108-Images.zip |
