PSSO PA Set PRO L

The article is no longer in our assortment.

No. 11041061

Print product

Product badge

Set consisting of:

2 x PSSO K-212 2-Way Top 300W

2 x PSSO K-152 Subwoofer 1000W

1 x OMNITRONIC SMA-1000 Amplifier

1 x OMNITRONIC SMA-2000 Amplifier

1 x OMNITRONIC DXO-24E Digital Controller

2 x OMNITRONIC Distance Tube Subwoofer/Satellite 120cm

1 x ROADINGER Amplifier Rack PR-2, 6U, 47cm deep

4 x PSSO Speaker Cable Speakon 2x2.5 15m bk

4 x PSSO XLR Cable 3-pin 1m bk Neutrik

1 x OMNITRONIC Front Panel Z-19U-shaped, steel, black 1U

Features

PSSO K-212 2-Way Top 300W

PRO PA speaker, 12" woofer, 1" horn, 300 W RMS, 8 ohms

Rugged full-range top speaker, qualified for suspension and touring applications
Housing made of 15 mm/18 mm birch plywood
30 cm (12") bass speaker with diecast aluminum basket
Rotatable 25 mm constant directivity horn tweeter (1", 44 mm voice coil)
Premium custom-made drivers by European manufacturer CELTO Acoustique
Passive 2-way crossover
Bassreflex system
Parallel Neutrik Speakon connectors
Trapezoidal multi-functional housing with scratch-resistant lacquer surface
Impact-resistant steel grille with acoustic foam
Flange for stand installation
Applications: standing, as monitor, on a subwoofer or speaker stand, suspended
CELTO ACOUSTIQUE driver
Built with NEUTRIK connector
European engineering

Package contents

1 x user manual, 1 x compact cabinet speaker

PSSO K-152 Subwoofer 1000W

PRO PA bassreflex subwoofer, 2 x 15" woofer, 1000 W RMS, 4 ohms

Rugged pro bassreflex subwoofer, qualified for touring applications
Housing made of birch plywood
2 x 38 cm (15") bass speaker with diecast aluminum basket
Premium custom-made drivers by European manufacturer CELTO Acoustique
Parallel Neutrik Speakon connectors
Metal flange for top speakers
Carrying handles and rubber feet
Matching castors optionally available
Scratch-resistant lacquer surface
Impact-resistant steel grille with acoustic foam
Wheels optional
CELTO ACOUSTIQUE driver
Built with NEUTRIK connector
European engineering

Package contents

1 x bass, 1 x user manual

OMNITRONIC SMA-1000 Amplifier

Stereo PA amplifier with limiter and SMPS, 2 x 500 W/4 ohms

Low weight and height due to integrated switch-mode power supply
Temperature-controlled fan, particularly quiet during operation
Limiter and speaker switch-on delay
Switchable bass-boost at 80 Hz with 6 dB level increase
3 operating modes can be selected (stereo, parallel or bridged)
Selectable input sensitivity
2 level controls
3 LEDs for each channel for activated protective circuit (protect) overload (clip) and signal
2 LEDs for parallel and bridge operation
Complete protection set against short-circuit, overheat, DC voltage and VHF signals
Electronically balanced inputs via XLR mounting jacks, with feed-through output (stereo RCA/6.3 mm jack)
Speaker outputs via lockable Speaker plugs
Class AB circuitry
Robust steel chassis
Rack installation with 2 units
(19") 48.3 cm rack installation

OMNITRONIC SMA-2000 Amplifier

Stereo PA amplifier with limiter and SMPS, 2 x 1000 W/4 ohms

Low weight and height due to integrated switch-mode power supply
Temperature-controlled fan, particularly quiet during operation
Limiter and speaker switch-on delay
Switchable bass-boost at 80 Hz with 6 dB level increase
3 operating modes can be selected (stereo, parallel or bridged)
Selectable input sensitivity
2 level controls
3 LEDs for each channel for activated protective circuit (protect) overload (clip) and signal
2 LEDs for parallel and bridge operation
Complete protection set against short-circuit, overheat, DC voltage and VHF signals
Electronically balanced inputs via XLR mounting jacks, with feed-through output (stereo RCA/6.3 mm jack)
Speaker outputs via lockable Speaker plugs
SMA-1500 and SMA-2000 with additional pairs of screw terminals for 8 ohms bridge operation
Class 2 H circuitry
Robust steel chassis
Rack installation with 2 units
(19") 48.3 cm rack installation 2 U

OMNITRONIC DXO-24E Digital Controller

Digital Speaker Management System with 2 inputs and 4 outputs, incl. software

Flexible routing configurations for all standard mono and stereo output operating modes
2 analog inputs and 4 analog outputs (XLR)
Active crossover with Bessel, Butterworth and Linkwitz-Riley filter with slopes up to 24 dB/octave
Up to 30 user presets storable in the device via software
Input sensitivity digitally adjustable
Inputs and outputs with 4-digit LED level meter as well as clip and limit LED indicator
Mute switch with LED indicator per output
7-band parametric EQ per output
Up to 7 ms signal delay adjustable for the outputs
Output limiter with adjustable limits and automatic attack and release settings as overload protection for your amplifying system
Switchable phase
Lock function for prevents undesired changes to settings
Sample rate: 67 kHz
(19") 48.3 cm rack installation 1 U
Digital signal processor
The device can be connected via USB to the PC in connection with DXO Software
firmware can be updated
Compatible with Win XP, Win Vista, Win 7, Win 10, OS X 10,5 or better
For application areas such as: Clubs/dancing school; installation; mobile djs / entertainer; restaurants, bars and hotels; rental

Package contents

1 x controller, 1 x user manual, 1 x external mains adapter, 1 x USB cable, 1 x CD, 4 x foot

OMNITRONIC Distance Tube Subwoofer/Satellite 120cm

Distance tube

Connecting tube for satellite systems
For stand inserts with standard diameter (35 mm)
Powder-coated steel version

ROADINGER Amplifier Rack PR-2, 6U, 47cm deep

Rack case

Front and rear rack rails
6 U
High-quality workmanship with plywood multi-layer glued 7 mm, black, laminated
Aluminum profile frames 30mm with rounded edges
2 hinged, chromium plated case handles
4 high-quality butterfly locks
Wooden slide rails on the bottom
Available in different height units (1 U = 44 mm)
With profile rails suitable for 19" units
For further information about this product, please refer to the Data Sheet under "Downloads"

PSSO Speaker Cable Speakon 2x2.5 15m bk

High-quality speaker cable

Built with NEUTRIK connector
Made in Germany

Package contents

1 x speaker cable

PSSO XLR Cable 3-pin 1m bk Neutrik

Reliable microphone cable

High quality connection for microphones etc.
High conductivity
Slim and short construction
Helukabel
Built with NEUTRIK connector
Made in Germany

Package contents

1 x XLR cable

OMNITRONIC Front Panel Z-19U-shaped, steel, black 1U

U-front panel in different sizes

Technical specifications

Weight:	176,76 kg
PSSO K-212 2-Way Top 300W
Power:	Program: 600W Rated: 300W RMS
Frequency range:	55 - 19000 Hz
Sensitivity:	97 dB (1W/1m)
Max. SPL:	128 dB
Dispersion angle:	90° x 60°
Impedance:	8 ohms
Connections:	Input: speaker via 2 x 2-pin SpeakON mounting version (F)
Crossover frequency:	1900 Hz
Speaker:	1 x woofer 12" 1 x horn 1"
Type of speaker:	Compact cabinet speaker
Use of brands:	CELTO ACOUSTIQUE driver Built with NEUTRIK connector
Dimensions:	Width: 34,7 cm Depth: 35,2 cm Height: 66 cm
Weight:	19,50 kg
PSSO K-152 Subwoofer 1000W
Power:	Program: 2000W Rated: 1000W RMS
Frequency range:	42 - 2200 Hz
Sensitivity:	100 dB (1W/1m)
Max. SPL:	136 dB
Impedance:	4 ohms
Connections:	Input: speaker via 2 x 2-pin SpeakON mounting version (F)
Speaker:	2 x woofer 15"
Type of speaker:	Subwoofer
Type of construction:	Vented
Transport aid:	Wheels optional
Use of brands:	CELTO ACOUSTIQUE driver Built with NEUTRIK connector
Dimensions:	Width: 47,6 cm Depth: 59 cm Height: 100 cm
Weight:	50,10 kg
OMNITRONIC SMA-1000 Amplifier
Power supply:	230 V AC, 50 Hz
Power consumption:	598,00 W
Output power:	Max. 964 W 2 x 482 W RMS (4 ohms) 2 x 340 W RMS (8 ohms)
Circuitry:	Class H
Housing design:	(19") 48.3 cm rack installation
Dimensions:	Width: 48,3 cm Depth: 39 cm Height: 8,9 cm
Weight:	7,25 kg
Power output sine:
stereo 4 ohms	2 x 482 W
stereo 8 ohms	2 x 340 W
8 ohms bridged	1 x 1000 W
Frequency range:	20-20000 Hz, ±0.5 dB
Damping factor:	>150
Distortion factor:	0.05 %
Slew rate:	>20 V/µsec
S/N ratio:	>90 dB
Channel seperation:	>70 dB/ 1 kHz
Input sensitivity:	26 dB/32 dB (2.48 V/1.244 V), switchable
Voltage gain:	26 dB/32 dB
Input impedance:	20 kohms (balanced), 10 kohms (unbalanced)
Input connectors:	stereo XLR
Output connectors:	stereo Speaker, feed-through output (stereo RCA, stereo 6.3 mm jack)
Circuitry:	class AB
Control elements:	power switch, level control per channel, mode switch (stereo/parallel/bridged), sensitivity selector, peak filter selector
LED indicators:	parallel, bridge (globally), protect, clip, signal (per channel)
Protection circuits:	short-circuit, overheat, DC voltage, VHF signals, softstart
Construction:	steel chassis
Dimensions (DxWxH):	390 x 483 x 92 mm (19", 2 U)
OMNITRONIC SMA-2000 Amplifier
Power supply:	230 V AC, 50 Hz
Power consumption:	575,00 W
Output power:	Max. 2000 W 2 x 1000 W RMS (4 ohms) 2 x 637 W RMS (8 ohms)
Power connection:	Fixed power supply cord with safety plug
Circuitry:	Class H
Housing design:	(19") 48.3 cm rack installation 2 U
Dimensions:	Width: 48,3 cm Depth: 39 cm Height: 8,9 cm
Weight:	9,55 kg
Power output sine:
stereo 4 ohms	2 x 1000 W
stereo 8 ohms	2 x 637 W
8 ohms bridged	1 x 2000 W
Frequency range:	20-20000 Hz, ±0.5 dB
Damping factor:	>150
Distortion factor:	0.05 %
Slew rate:	>20 V/µsec
S/N ratio:	>90 dB
Channel seperation:	>70 dB/ 1 kHz
Input sensitivity:	26 dB/32 dB (3.46 V/1.73 V), switchable
Voltage gain:	26 dB/32 dB
Input impedance:	20 kohms (balanced), 10 kohms (unbalanced)
Input connectors:	stereo XLR
Output connectors:	stereo Speaker, 2 pairs of screw terminals, feed-through output (stereo RCA, stereo 6.3 mm jack)
Circuitry:	class 2 H
Control elements:	power switch, level control per channel, mode switch (stereo/parallel/bridged), sensitivity selector, peak filter selector
LED indicators:	parallel, bridge (globally), protect, clip, signal (per channel)
Protection circuits:	short-circuit, overheat, DC voltage, VHF signals, softstart
Construction:	steel chassis
Dimensions (DxWxH):	390 x 483 x 92 mm (19", 2 U)
OMNITRONIC DXO-24E Digital Controller
Power supply:	100-240 V AC, 50/60 Hz 6V 800 mA
Power connection:	Mains input via coaxial power connector (M) mounting version power supply cord with AC adapter (provided)
Frequency range:	10 - 30000 Hz
THD:	<0,005 % at 1 kHz
DSP:	Digital signal processor
Impedance:	Input: 10 kOhm Output: 50 Ohm
Gain:	Output: -50 dB to +12 dB
Filter:	Linkwitz-Riley; Butterworth; Bessel; 6db/oct; 12db/oct; 18db/oct; 24db/oct
Delay:	0 - 5 ms
Dynamic range:	Input: 114 dB Output: 110 dB
Sample rate:	67 kHz
Connections:	Input: line via 2 x 3-pin XLR Output: line via 4 x 3-pin XLR
Crossover frequency:	20-20000 Hz
Max. level:	Input: +22 dBu Output: +9 dBu
USB port:	Type B
PC connect:	DXO Software via USB, firmware can be updated
Housing design:	(19") 48.3 cm rack installation 1 U
Dimensions:	Width: 48,3 cm Depth: 12,8 cm Height: 4,45 cm
Weight:	1,60 kg
Operating system:	Win XP, Win Vista, Win 7, Win 10, OS X 10,5 or better
OMNITRONIC Distance Tube Subwoofer/Satellite 120cm
Maximum carrying capacity:	35 kg
Attachment system:	Ø 35mm
Type (general stands):	Distance tube
Material:	Steel
Color:	Black
Dimensions:	Height: 120 cm Diameter: Ø 3,5 cm
Weight:	0,96 kg
ROADINGER Amplifier Rack PR-2, 6U, 47cm deep
Maximum load:	50 kg
Aluminum profile frames:	30 mm
Case handle:	2 pc/pcs
Lock:	Butterfly lock: 4 pc/pcs
Transport aid:	Wooden slide rails on the bottom
Material:	Plywood multi-layer glued, 7 mm
Color:	Black, laminated
Front panel width:	19"
Mounting height:	Approx. 26.5 cm (6 U)
Mounting depth:	420 mm
Housing design:	6 U
Dimensions:	Width: 54,5 cm Depth: 64 cm Height: 32 cm
Weight:	10,50 kg
PSSO Speaker Cable Speakon 2x2.5 15m bk
Cable construction:	2 x 2,5 mm² speaker cable
Cable length:	15 m
Plug A:	1 x 2-pin SpeakON (M)
Plug B:	1 x 2-pin SpeakON (M)
Use of brands:	Built with NEUTRIK connector
Color:	Black
Weight:	1,50 kg
PSSO XLR Cable 3-pin 1m bk Neutrik
Cable construction:	2 x 0,22 mm² microphone cable
Cable length:	1 m
Plug A:	1 x 3-pin XLR (M), Typ NC3MXX
Plug B:	1 x 3-pin XLR (F), Typ NC3FXX
Use of brands:	Helukabel Built with NEUTRIK connector
Color:	Black
Weight:	0,11 kg
OMNITRONIC Front Panel Z-19U-shaped, steel, black 1U
Diameter mounting holes:	Ø7mm
Material:	Steel, 1 mm
Color:	Black, powder-coated
Mounting height:	Approx. 4.5 cm (1 U)
Housing design:	1 U
Dimensions:	Width: 48,3 cm Height: 4,45 cm
Weight:	0,30 kg

Accessories

Loading accessories. Please wait...

Support

Spare parts

Transistor TIP 122

Cable USB A male > B male 1m

Temperature switch 105°C SMA

More 54 spare parts

Downloads

Loading the documents. Please wait...

Manufacturer information

Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
D-97297 Waldbüttelbrunn

+49 931 4061 600
info@steinigke.de
www.steinigke.de/support
